14.6 Technical specifications: Indoor unit
Specification EHVH_SU18 EHVH_SU26
Maximum water supply pressure to pressure reducing valve 16bar
Operating pressure/set pressure of pressure reducing valve 3.5bar
Maximum primary working pressure (heating) 2.5bar
Maximum flow temperature 65°C
Expansion vessels pre-charge pressure (in domestic hot water tank kit) 2.5bar
Expansion valve setting 8bar
Temperature and pressure relief
valve
Set opening temperature 90~95°C
Set opening pressure 10bar
Replacement part number 302810P
Operating temperature of thermal cut-out when installed with ERHQ or
ERLQ
79~85°C
Primary heating power input 24.5kW 21.1kW
Primary flow rate to reach primary heating power input 15l/min
Standing heat losses 2.4kWh/24h 2.6kWh/24h
Actual capacity 172l 249l
Mass of unit when full 229.5kg 309.5kg
Maximum design pressure 10bar
Heat-up times 18'54" 28'50"
Type of corrosion protection Electronic anode
