INSTALLATION
Cleaning air suction filter
To remove the grill:
- lift the grill until it is completely released from the seat
- lit the grill and slide it outwards
- then remove the filter by pulling it outwards
Extraction of filter cells
After a period of continuous operation and in consideration
of the concentration of impurities in the air, or when he
intends to restart the plant after a period of inactivity,
proceed as described.
Front grill
Grill hook
Filter
