5. Technical data
Nominal input voltage 230V ~ 50 Hz
Power rating 350 W
Operating mode S2 15 min.
Motor speed 1,400 rpm
Output speed 580 - 2,650 rpm
Speed levels 5
Drill chuck mount B 16
Scroll chuck Ø 1.5 - 13 mm
Max. shaft diameter 13 mm
Reach 104 mm
Drill depth 50 mm
Pillar diameter 46 mm
Height 590 mm
Weight 18 kg
L
pA
sound pressure level 61.5 dB(A)
L
WA
sound power level 74.5 dB(A)
K
pA
uncertainty 3 dB
K
WA
uncertainty 3 dB
Sound and vibration
Sound and vibration values were measured in
accordance with EN 61029.
Load factor:
A load factor of S2 15 min (intermittent periodic duty)
means that you may operate the motor continuously
at its nominal power level (350 W) for no longer than
the time stipulated on the specifications label (15
minutes ON period).
If you fail to observe this time limit the motor will
overheat. During the OFF period the motor will cool
again to its starting temperature.
Keep the noise emissions and vibrations to a
minimum.
Only use appliances which are in perfect working
order.
Service and clean the appliance regularly.
Adapt your working style to suit the appliance.
Do not overload the appliance.
Have the appliance serviced whenever
necessary.
Switch the appliance off when it is not in use.
Wear protective gloves.
Residual risks
Even if you use this electric power tool in
accordance with instructions, certain residual
risks cannot be rules out. The following hazards
may arise in connection with the equipment’s
construction and layout:
1. Damage to hearing if no suitable ear protection is
used.
6. Before starting the equipment
6.1. Assembling the machine
Position the machine base (1).
Fasten mounting flange with pillar (2) using three
screws (3) and washers to drill base (1).
Push the drill table (4) with drill table clamp shaft
onto the pillar (2) (Fig. 4). Lock the drill table into
the desired position using the clamping screw (5).
Place drill head (6) with V-belt cover (7) and
motor (8) onto the drill pillar and fasten using the
Allen screws (20).
Screw the three ball-shaped handles (9) onto the
feeder cross handle.
Note: All bare parts are greased in order to protect
them from corrosion. Before mounting the drill chuck
(10) onto the spindle (11), both parts must be
completely degreased using an environmentally
friendly solvent. This ensures optimal transmission of
power.
6.2. Installing the machine (Fig. 1)
Before you use the drill for the first time it must be
permanently fixed in position. Use both mounting
holes (12) in the base plate to do this. Ensure that the
equipment is freely accessible for operation,
adjustment and maintenance.
Note: The fixing screws may only be tightened to a
point where they do not distort or deform the base
plate. Excessive tension can lead to fracture.
6.3. Hinged chip guard (Fig. 4)
Unscrew the three screws (21). Push the transparent
cover (23) into the groove of the red mounting frame
(24) and fasten it again with the screws (21).
The height of the cover (23) is infinitely adjustable
and can be locked using both thumb screws (22).
The chip guard (13) can be flipped upwards to
change drill bits, however ensure that the chip guard
(13) is back in its initial position before restarting the
equipment.
