7.7 Clamping the workpiece

As a general rule, use a machine vice or another

suitable clamping device to lock a workpiece into

position. Never hold the workpiece in place with

your hand! When drilling, the workpiece should be

able to travel on the drill table (4) for self-centering

purposes. Ensure that the workpiece cannot rotate.

This is best achieved by placing the

workpiece/machine vice on a sturdy block.

Important. Sheetmetal parts must be clamped in to

prevent them from being torn up. Properly set the

height and angle of the drill table for each workpiece.

There must be enough distance between the upper

edge of the workpiece and tip of the drill bit.

7.8 Working speeds

Ensure that you drill at the proper speed. Drill speed

is dependent on the diameter of the drill bit and the

material it is made from.

The table below acts as a guide for selecting the

proper speed for drill bits made from various

materials.

Note: The rotational speeds shown are merely

suggested values.

Drill bit Ø Cast iron Steel Iron Aluminum Bronze

3 2550 1600 2230 9500 8000

4 1900 1200 1680 7200 6000

5 1530 955 1340 5700 4800

6 1270 800 1100 4800 4000

7 1090 680 960 4100 3400

8 960 600 840 3600 3000

9 850 530 740 3200 2650

10 765 480 670 2860 2400

11 700 435 610 2600 2170

12 640 400 560 2400 2000

13 590 370 515 2200 1840

14 545 340 480 2000 1700

16 480 300 420 1800 1500

18 425 265 370 1600 1300

20 380 240 335 1400 1200

22 350 220 305 1300 1100

25 305 190 270 1150 950

7.9 Countersinking and center-drilling

With this drill you can also perform countersinking

and center-drilling jobs. Please observe that

countersinking should be performed at the lowest

speed, while a high speed is required for center-

drilling.

7.10 Woodworking

Please note that sawdust must be properly evacuated

when working with wood, as it can be a health

hazard. Ensure that you wear a suitable dust mask

when performing work that generates dust.

8. Replacing the power cable

If the power cable for this equipment is damaged, it

must be replaced by the manufacturer or its after-

sales service or similarly trained personnel to avoid

danger.

9. Cleaning, maintenance and ordering

of spare parts

Always pull out the mains power plug before starting

any cleaning work.

9.1 Cleaning

 The drill is maintenance-free to a large extent.

Keep the equipment clean. Pull the power plug

before doing any cleaning and maintenance work

on the appliance. Do not use any harsh, abrasive

solvents to clean. Ensure that no liquid seeps into

the equipment. Regrease all bare parts when the

work is finished. The drill pillar, blank parts of the

column, and the drill table especially should be

regreased at regular intervals. Use a standard,

acid-free lubricating grease to do this.

Important: Do not use your household trash can

as a receptacle for oil and grease-soaked

cleaning rags or grease and oil sludge. Dispose

of these toxic materials in an environmentally-

friendly fashion. Regularly check and clean the

ventilation holes. Store the equipment in a dry

room. Should the equipment become damaged,

do not try to repair it yourself. Leave this work to

the hands of a qualified electrical technician.

 We recommend that you clean the equipment

immediately after you use it.

 Clean the appliance regularly with a damp cloth

and some soft soap. Do not use cleaning agents

or solvents; these may be aggressive to the

plastic parts in the appliance. Ensure that no

water can get into the interior of the equipment.

9.2 Servicing

There are no parts inside the equipment which

require additional maintenance.

14
