Daikin RKHBRD014ADV1 [5/24] Setting the clock

RKHBRD011~016ADV1+Y1

Indoor unit for air to water heat pump system and options

4P403582-1 – 2015.04

Operation manual

24. DOMESTIC WATER HEATING BUTTON

This button enables or disables the different domestic hot water

modes in combination with the schedule timer button.

This button is not used when the domestic hot water tank is not

installed.

25. WEATHER DEPENDENT SET POINT BUTTON

This button enables or disables the weather dependent set point

function which is available in space heating operation.

If the controller is set to permission level 3 (refer to "Field

settings" in the installation manual), the weather dependent set

point button will not be operable.

26. INSPECTION/TEST OPERATION BUTTON

This button is used for installation purposes and changing ﬁeld

settings. Refer to "Field settings" on page 16.

27. PROGRAMMING BUTTON

This multi-purpose button is used to program the controller. The

function of the button depends on the actual status of the

controller or on previous actions carried out by the operator.

28. SCHEDULE TIMER BUTTON /

The main function of this multi-purpose button is to

enable/disable the schedule timer.

The button is also used to set the clock and to program the

controller. The function of the button depends on the actual

status of the controller or on previous actions carried out by the

operator.

29. TIME ADJUST BUTTONS and

These multi-purpose buttons are used to adjust the clock, to

toggle between temperatures (water inlet/outlet temperature of

the indoor unit, outdoor ambient temperature, actual room

temperature and domestic hot water temperature) and in

schedule timer programming mode.

30. LEAVING WATER TEMPERATURE ADJUST BUTTONS

and

These buttons are used to adjust the leaving water temperature

set point in normal operation mode or in schedule timer

programming mode.

If the controller is set to permission level 3 (refer to "Field

settings" in the installation manual), the leaving water

temperature adjust button will not be operable.

In case the weather dependent set point operation is selected,

the unit has a ﬂoating set point. In this case, the icon as well

as the shift value (in case not zero) will display.

31. ROOM TEMPERATURE ADJUST BUTTONS and

These multi-purpose buttons are used to adjust the current room

temperature set point in normal operation mode or in schedule

timer programming mode.

When changing the room temperature set point, the set point

value on the display will be ﬂashing. After 5 seconds the display

will show to the actual room temperature.

32. QUIET MODE BUTTON

This button enables or disables quiet mode.

If the controller is set to permission level 2 or 3 (refer to "Field

settings" in the installation manual), the quiet mode button will

not be operable.

33. The

button has no function.

Setting the clock

After initial installation, the user can set the clock and day of the week.

The remote controller is equipped with a schedule timer that enables

the user to schedule operations. Setting the clock and day of the

week is required to be able to use the schedule timer.

1 Hold down the button for 5 seconds.

The clock read-out and the day of week indicator start ﬂashing.

2 Use the and buttons to adjust the clock.

Each time the or button is pressed, the time will

increase/decrease by 1 minute. Keeping the or

button pressed will increase/decrease the time by 10 minutes.

3 Use the or button to adjust the day of the week.

Each time the or button is pressed the next or

previous day is displayed.

4 Press the button to conﬁrm the current set time and day of the

week.

To leave this procedure without saving, press the button.

If no button is pressed for 5 minutes the clock and day of the

week will return to their previous setting.

NOTE

Remark that pushing the button has no

inﬂuence on the domestic water heating.

Domestic water heating is only switched on or off

by means of the button and/or disabling the

storage schedule timer.

NOTE

■ The clock needs to be set manually. Adjust the

setting when switching from summertime to

wintertime and vice versa.

■ If the controller is set to permission level 2 or 3

(refer to "Field settings" in the installation

manual), setting the clock will not be possible.

■ A power failure exceeding 1 hour will reset the

clock and the day of the week. The schedule timer

will continue operation, but with a disordered

clock. Therefor it will be needed to correct the

clock and the day of the week.
