26
Any other use shall be considered as not intended use and can
lead to material damage or even personal injury.
The manufacturer shall not be liable for damages caused by
not intended use.
Supplied parts
1 base device with motor
1 transparent cover
1 tamper
1 centrifuge sieve
1 centrifuge housing
1 pomace container
Unpacking the appliance
1. Remove the device from its packaging.
2. Remove all packaging materials like foils, lling materials,
cable holders, and carton packaging.
3. Check the scope of deliveries for completeness.
NOTE:
There may still be dust or production remains on the device.
We recommend that you clean the device as described under
“Cleaning”.
Description of the Parts
1 Tamper
2 Filler opening
3 Transparent cover
4 Centrifugal sieve
5 Centrifuge casing
6 Spout
7 Drive wheel (not detachable)
8 Safety bracket
9 Base device with motor
10 Setting selector
11 Pomace container
Setting up of the appliance
For assembly, also refer to the illustrations on page 3.
1. Set the device so that the switch points towards you.
2. Tilt the safety handle to the right.
3. Attach the centrifuge casing on top of the base casing. The
base casing has a recess. Here the spout of the centrifuge
casing must be placed.
WARNING risk of cuts!
The centrifugal sieve is sharp!
4. Place the centrifugal sieve on top of the drive wheel. Press
it down. It clicks in place on the drive wheel.
5. Check the centrifugal sieve! Feel under the sieve edge. It
should not loosen under slight tension.
6. Attach the pulp container on the left side. To do so, hold it
slightly sideways to press the upper edge into the shroud of
the centrifuge housing.
7. Attach the transparent cover. It reaches all the way over the
pulp container.
NOTE:
Your appliance is equipped with a safety switch. It
prevents accidental motor start. Check the correct attach-
ment of all components, centrifugal sieve and transparent
cover.
8. Lock the safety bracket over the transparent cover.
9. Press the spout downwards to open the ow of the juice.
10. Place the juice jug to the right of the appliance.
11. Ensure that the control knob is set to “0” position.
Electric Connection
• Before inserting the power plug into the outlet, check that
the mains voltage to be used matches that of the device.
You can nd the required information on the nameplate.
• Connect the device only to a correctly installed safety
socket.
Operation
Switch settings
• Select step 1 for smaller fruit like strawberries.
• Select step 2 for larger pieces or hard vegetables, for
example carrots.
Preparations
• Wash the fruit to be processed.
• Cut the fruit in pieces to t through the ller opening.
• Remove large pips and stems.
Extracting Juice
NOTE:
The appliance is intended for short-term use. After operating
it for 3 minutes, take a 5 minute break.
WARNING!
• Check all accessories again for proper attachment before
switching the appliance on.
• Ensure that the spout is pressed downwards.
1. Set the switch to the desired position. The motor starts
running.
2. Insert the fruit pieces in the ller opening and push them
down with the tamper. Please note! The tamper has a
guide way in the ller opening.
3. The juice ows out at the right side of the casing. The pulp
is collected in the pulp container. If there is an excessive
discharge of juice, switch to setting 1 and exert less pres-
sure on the pusher.
