Daikin LRYEN10A7Y1 [105/140] Charging refrigerant
![Daikin LRYEN10A7Y1 [105/140] Charging refrigerant](/views2/1801919/page105/bg69.png)
18 | Charging refrigerant
Installer and user reference guide
105
LRYEN10A7Y1+LRNUN5A7Y1
CO₂ Conveni-Pack outdoor unit
4P605460-1 – 2020.08
Calculation table: outdoor unit with or without capacity up unit
Amount of refrigerant for liquid piping (refrigeration / air conditioner)
Liquid piping
size (mm)
Conversion
ratio per
meter of
liquid piping
(kg/m)
Piping length
(m)
Total amount
of refrigerant
(kg)
Ø9.5 0.0463 (a)
Ø12.7 0.0815 (b)
Ø15.9 0.1266 (c)
Subtotal (a)+(b)+(c): [1]
Amount of refrigerant for indoor units
Type of indoor unit Total amount
of refrigerant
(kg)
Blower coils (d)
Showcases (e)
Air conditioner units (f)
Subtotal (d)+(e)+(f): [2]
Required amount of refrigerant for outdoor unit (kg) 16.0 [3]
Subtotal [1]+[2]+[3] (kg) [4]
Factory charged amount of refrigerant into outdoor unit (kg) 6.3 [5]
Additional amount of refrigerant charged when test run if
required (kg)
[6]
Total amount of refrigerant [4]+[5]+[6] (kg)
(a)
[7]
(a)
The maximum amount of additional refrigerant that can be charged at the time of the test
run is 10% of the amount of refrigerant as calculated from the capacity of connected
indoor units. Use [6]≤[2]×0.1 to calculate this maximum amount.
Conversion ratio for indoor units: refrigeration
Type Conversion ratio
Blower coil 0.059kg/kW
Showcase 0.294kg/kW
Conversion ratio for indoor units: air conditioners
Model Conversion ratio
FXSN50 0.13kg/unit
FXSN71 0.21kg/unit
FXSN112 0.32kg/unit
