17 | Electrical installation
Installer and user reference guide
94
LRYEN10A7Y1+LRNUN5A7Y1
CO₂ Conveni-Pack outdoor unit
4P605460-1 – 2020.08
f Wiring intake (knockout hole) for low voltage. See "17.3Guidelines when knocking out knockout
holes"[490].
Details – DIII transmission wiring
See "17.5Specifications of standard wiring components"[492].
Details – Remote operation switch
NOTICE
Remote operation switch. The unit is factory-equipped with an operation switch
with which you can turn unit operation ON/OFF. If you want to remotely turn ON/
OFF operation of the outdoor unit, a remote operation switch is required. Use a
voltage-free contact for microcurrent (≤1mA, 12 VDC). Connect to X5M/1+2, and
set to "Remote".
REMOTE
OFF
ON
S1S
S1S Factory-equipped operation switch:
OFF: Unit operation turned OFF
ON: Unit operation turned ON
Remote: Unit controlled (ON/OFF) with remote operation switch
Wiring remote operation switch:
Wiring Sheathed cable (2 wires)
Vinyl cords
0.75~1.25mm²
Maximum wiring length 130m
Details – Remote low noise switch
NOTICE
Low noise switch. If you want to remotely turn ON/OFF low noise operation, you
must install a low noise switch. Use a voltage-free contact for microcurrent (≤1mA,
12VDC).
Low noise switch Mode
OFF Normal mode
ON Low noise mode
Wiring low noise switch:
Wiring Sheathed cable (2 wires)
Vinyl cords
0.75~1.25mm²
Maximum wiring length 130m
