Daikin LRYEN10A7Y1 [134/140] Wiring diagram outdoor unit
![Daikin LRYEN10A7Y1 [134/140] Wiring diagram outdoor unit](/views2/1801919/page134/bg86.png)
26 | Technical data
Installer and user reference guide
134
LRYEN10A7Y1+LRNUN5A7Y1
CO₂ Conveni-Pack outdoor unit
4P605460-1 – 2020.08
26.4 Wiring diagram: Outdoor unit
The wiring diagram is delivered with the unit:
▪ For the outdoor unit: At the inside of the left electrical component box cover.
▪ For the capacity up unit: At the inside of the electrical component box cover.
Outdoor unit
Notes:
1 This wiring diagram applies only to the outdoor unit.
2 Field wiring
3 Terminal block
Connector
Terminal
Protective earth (screw)
4 S1S is factory set to OFF. Set to ON or REMOTE to operate.
5 Use a voltage-free contact for microcurrent (≤1mA, 12VDC). For more
information about the remote switches, see details in "17.6.1Low voltage
wiring – Outdoor unit"[493].
6 Output (caution, warning, run, operation) is 220-240VAC, with a
maximum load of 0.5A.
7 For more information about the BS1~BS3 push buttons and the DS1+DS2
DIP switches, see "20.2Making field settings"[4108].
8 Do not operate the unit by short-circuiting protection devices (S1PH, S2PH
and S3PH).
9 Colours:
BLK Black
RED Red
BLU Blue
WHT White
GRN Green
YLW Yellow
PNK Pink
Legend:
A1P Printed circuit board (main 1)
A2P Printed circuit board (main 2)
A3P Printed circuit board (M1C)
A4P Printed circuit board (M2C)
A5P Printed circuit board (M3C)
A6P Printed circuit board (noise filter) (M1C)
A7P Printed circuit board (noise filter) (M2C)
A8P Printed circuit board (noise filter) (M3C)
