26 | Technical data
Installer and user reference guide
135
LRYEN10A7Y1+LRNUN5A7Y1
CO₂ Conveni-Pack outdoor unit
4P605460-1 – 2020.08
A9P Printed circuit board (M1F)
A10P Printed circuit board (M2F)
A11P Printed circuit board (M3F)
A12P Printed circuit board (sub)
A13P Printed circuit board (ABC I/P 1)
A14P Printed circuit board (earth leakage detector)
E1HC Crankcase heater (M1C)
E2HC Crankcase heater (M2C)
E3HC Crankcase heater (M3C)
L1R Reactor (A3P)
L2R Reactor (A4P)
L3R Reactor (A5P)
M1C Motor (compressor) (INV1)
M2C Motor (compressor) (INV2)
M3C Motor (compressor) (INV3)
M1F Motor (fan) (FAN1)
M2F Motor (fan) (FAN2)
M3F Motor (fan) (FAN3)
R1T Thermistor (air) (A1P)
R21T Thermistor (M1C suction)
R22T Thermistor (M2C suction)
R23T Thermistor (M3C suction)
R31T Thermistor (M1C discharge)
R32T Thermistor (M2C discharge)
R33T Thermistor (M3C discharge)
R4T Thermistor (de-icer)
R7T Thermistor (liquid)
R8T Thermistor (sub-cool heat exchanger outlet)
R91T Thermistor (M1C body)
R92T Thermistor (M2C body)
R93T Thermistor (M3C body)
S1NPH High pressure sensor
S1NPM Medium pressure sensor (liquid)
S2NPM Medium pressure sensor (M3C suction)
S1NPL Low pressure sensor (refrigeration)
S2NPL Low pressure sensor (air conditioner)
S1PH Pressure switch (high pressure protection) (M1C)
S2PH Pressure switch (high pressure protection) (M2C)
