25
Start-up
NOTE:
Direct mains power operation is not possible.
Charge Batteries
• Switch the device off.
• Connect the DC connector to the DC input (13) on the
device.
• Connect the power adaptor to a properly installed earthed
wall outlet 230 V~ 50 Hz.
CAUTION:
Place the mains cable in such way that it does not become a
trip hazard.
NOTE:
• The switch illumination ashes during the charging
process.
• Charging takes 16 hours beforerst use and 12 hours for
following charges.
• The batteries are fully charged when the switch illumina-
tion lights up continuously.
• Disconnect the device from the power adaptor.
• Disconnect the power adaptor from mains power supply.
On / Off
Press the On / Off switch (9) to switch the device on or off.
NOTE:
The switch illumination lights up during operation.
Operating Instructions
Telescopic Handle
The handle is equipped with a telescopic tube for individual
lengthening or shortening.
• Slide the release button (11) with one hand towards the
icon. Use the other hand to extract the handle from the
telescopic tube.
• Extract the telescopic tube as far as desired. Release the
button (11) to lock the telescopic tube in place.
• Follow the same steps to retract the telescopic tube. Slide
the release button (11) towards the icon while pushing
the telescopic tube with the other hand.
Nozzle Attachments
• Use the brush nozzle attachment (16) for upholstery. Con-
nect the nozzle attachment with theat side down to the
suction opening (15). For removal pull the attachment off
again.
• Use the crevice nozzle attachment (17) to easily vacuum
corners and crevices. Connect the nozzle attachment with
the at side down in the direction of the arrow to the suction
opening (15). For removal pull the attachment off again.
• For larger areas use the turbo oor brush (18). Connect the
brush attachment with the electrodes (20) aligned with the
electrode connectors (14) to the suction opening (15). The
oor brush will click into place. Press the lock button (19) to
disconnect and pull the brush attachment off.
Cleaning and Maintenance
WARNING:
•
Always disconnect the device from the power adaptor before
cleaning!
• Do not submerge the device in water.
CAUTION:
•
Do not use a wire brush or other abrasives for cleaning.
• Do not use aggressive or abrasive cleaning agents.
Clean the casing with a dry cloth.
Filter
Observe the illustrations on page 4!
• Press the release button (2) to remove the dust container.
(Fig. a)
• Remove thelter holder (5). Empty the dust container into a
trash bin. (Fig. b)
• Turn the lter basket (3) towards to remove it (Fig. c).
Clean the lter basket with a brush.
• Remove thelter eece (4) to empty it. (Fig. d)
• Clean dust container, lter basket,lter eece and lter
holder under running water, if necessary. (Fig. e)
CAUTION:
• Only reassemble these parts completely dry!
• Do not wash thelters in the washing machine; do not
use a hair dryer for drying.
Floor Brush
Observe the illustrations on page 4!
• Slide button (21) forward to remove the cover for the round
brush. (Fig. h and i)
• Cut threads and hair, which may have coiled around the
round brush. (Fig. k)
• Clean the round brush under running water, if necessary.
(Fig. l)
CAUTION:
Only reassemble these parts completely dry!
•
Attach the round brush rst on the left hand side. The square
prole is aligned with the cover. (Fig. m)
• Insert the square prole in the oor brush.
• Close the cover (22). (Fig. n)
