02_NVspec_ver202e_pdf.xls 2_Object Details
2-4.LOSSNAY
(1)LOSSNAY interlocks with the indoor unit.(note 1,3)
Indoor[1]-[50]
Network Variables
nv14n
nvoLCMode_n
SNVT switch
nv16n
nvoAlarm_n
SNVT switch
（note.4）
(2)LOSSNAY is operation from L
ON
W
ORKS
.(note 5,6)
Indoor[1]-[50]
Network Variables
nv1n
nviOnOff_n
SNVT switch
nv2n
nvoOnOff_n
SNVT switch
nv13n
nviLCMode_n
SNVT switch
nv14n
nvoLCMode_n
SNVT switch
nv7n
nviFanSpeed_n
SNVT switch
nv8n
nvoFanSpeed_n
SNVT switch
nv16n
nvoAlarm_n
SNVT switch
（note 4）
NOTES:
1. stencil for LonMaker:iLOSSNAY[1]-[50]
2. "n" of the network variable shows M-NET address of LOSSNAY.
3. There is a case which cannot be used with the system configuration of the air conditioners units.
4. There is a case which cannot be used with the system configuration of the air conditioners units or the
model of LOSSNAY.
5.
Please turn ON the switch
(
SW1-5
)
when LOSSNAY is o
p
eration from L
ON
W
ORKS
.
(
Factor
y
settin
g
"OFF"
)
6. stencil for LonMaker:LOSSNAY[1]-[50]
WLN01-1023(Ver2.02) - 6 -
