6.9 Reliable performance
a. High COP
High efficiency and great energy saving are the purchased aim for every air conditioning
manufacturer. Haier MRVII has been designed to get high COP from the reasonable structure and
the excellent electric system.
b. Approved for RoHS certificate
All the parts in the unit have been approved for RoHS certificate. The parts are in conformance
with RoHS directive. Thus Haier MRVII will be environmental for human and nature.
The directive is to approximate the laws of the Member States on the restrictions of the use of
hazardous substances in electrical and electronics equipment and to contribute to the protection of
human health and the environmentally sound recovery and disposal of waste electrical and
electronic equipment.
10HP
COP 3.95
12HP
COP 4.12
c. Less chance of refrigerant leakage
The connection type of outdoor gas stop valve is brazed, therefore it is not easy to leak any
refrigerant.
Cooling operation condition: indoor temp is 27
0
CDB/19
0
CWB; outdoor temp is 35
0
CDB/24
0
CWB;
Heating operation condition: indoor temp is 20
0
DB, outdoor temp is 7
0
CDB/6
0
CWB.
EER 3.80
EER 3.90
HEATING
COOLING
8HP
COP 4.24
EER 4.28
14HP
COP 3.85
EER 3.25
16HP
COP 3.90
EER 3.20
