Haier AV26NMVERA [337/531] Av26nmvera heating mode
![Haier AV26NMVERA [337/531] Av26nmvera heating mode](/views2/1816541/page337/bg151.png)
TC PI TC PI TC PI TC PI TC PI TC PI
℃DB ℃WB
KW KW KW KW KW KW KW KW KW KW KW KW
-14.7 -15.0 49.4 12.9 49.4 13.7 49.4 14.5 49.3 14.9 49.3 15.2 49.3 16.0
-12.6 -13.0 52.3 13.7 52.3 14.5 52.3 15.2 52.3 15.5 52.3 15.9 52.3 16.6
-10.5 -11.0 55.4 14.4 55.4 15.1 55.4 15.8 55.4 16.1 55.4 16.5 55.4 17.1
-9.5 -10.0 57.1 14.8 57.1 15.4 57.1 16.1 57.1 16.4 57.1 16.8 57.1 17.5
-8.5 -9.1 58.4 15.1 58.4 15.7 58.4 16.3 58.4 16.7 58.4 16.9 58.4 17.6
-7.0 -7.6 60.7 15.5 60.7 16.1 60.7 16.7 60.7 17.1 60.7 17.3 60.7 18.0
-5.0 -5.6 63.7 16.0 63.7 16.6 63.7 17.1 63.7 17.5 63.7 17.8 63.7 18.3
-3.0 -3.7 66.6 16.5 66.6 16.9 66.6 17.6 66.6 18.0 66.6 18.1 66.6 18.8
0.0 -0.7 71.3 17.1 71.3 17.6 71.3 18.1 71.3 18.5 71.3 18.6 71.3 19.1
3.0 2.2 75.5 17.6 75.5 18.1 75.5 18.6 75.5 18.8 75.5 19.1 75.5 19.6
5.0 4.1 78.6 18.0 78.6 18.5 78.6 19.0 78.6 19.1 78.6 19.5 78.6 19.8
7.0 6.0 81.5 18.3 81.5 18.8 81.5 19.1 81.5 19.5 81.5 19.6 81.5 20.1
9.0 7.9 84.4 18.5 84.3 19.0 84.3 19.5 84.3 19.6 84.3 19.8 84.3 20.3
11.0 9.8 87.3 18.8 87.3 19.1 87.3 19.6 87.3 19.8 87.3 20.1 87.3 20.5
13.0 11.8 90.5 19.0 90.5 19.5 90.5 19.8 90.5 20.1 90.5 20.3 90.5 20.6
15.0 13.7 93.3 19.3 93.2 19.6 93.2 20.0 93.2 20.3 93.2 20.5 92.3 20.5
19.0 14.2 93.3 19.5 93.2 19.8 93.2 20.2 93.2 20.5 93.2 20.7 92.3 20.1
21.0 15.0 93.3 19.6 93.2 20.0 93.2 20.3 93.2 20.6 93.2 20.3 92.3 19.9
-14.7 -15.0 49.4 14.0 49.3 14.7 49.3 15.4 49.3 15.7 49.3 16.1 49.3 16.8
-12.6 -13.0 52.3 14.7 52.3 15.4 52.3 16.0 52.3 16.4 52.3 16.7 52.3 17.5
-10.5 -11.0 55.4 15.4 55.4 16.0 55.4 16.6 55.4 16.9 55.4 17.3 55.4 18.0
-9.5 -10.0 57.1 15.7 57.1 16.3 57.1 16.9 57.1 17.1 57.1 17.5 57.1 18.1
-8.5 -9.1 58.4 15.9 58.4 16.5 58.4 17.1 58.4 17.5 58.4 17.8 58.4 18.3
-7.0 -7.6 60.7 16.3 60.7 16.9 60.7 17.5 60.7 17.8 60.7 18.0 60.7 18.6
-5.0 -5.6 63.7 16.8 63.7 17.3 63.7 18.0 63.7 18.1 63.7 18.5 63.7 19.0
-3.0 -3.7 66.6 17.3 66.6 17.8 66.6 18.3 66.6 18.5 66.6 18.8 66.6 19.3
0.0 -0.7 71.3 17.8 71.3 18.3 71.3 18.8 71.3 19.0 71.3 19.3 71.3 19.8
3.0 2.2 75.5 18.3 75.5 18.8 75.5 19.3 75.5 19.5 75.5 19.6 75.5 20.1
5.0 4.1 78.6 18.6 78.6 19.0 78.6 19.5 78.6 19.6 78.6 20.0 78.6 20.3
7.0 6.0 81.5 18.8 81.5 19.3 81.5 19.8 81.5 20.0 81.5 20.1 81.5 20.6
9.0 7.9 84.3 19.1 84.3 19.5 84.3 20.0 84.3 20.1 84.3 20.3 84.3 20.8
11.0 9.8 87.3 19.3 87.3 19.8 87.3 20.1 87.3 20.3 87.3 20.5 85.2 20.1
13.0 11.8 90.5 19.6 90.5 20.0 90.5 20.3 90.5 20.5 90.5 20.8 85.2 19.5
15.0 13.7 93.2 19.8 93.2 20.1 93.2 20.5 93.2 20.6 91.8 20.3 85.2 18.6
19.0 14.2 93.2 20.0 93.2 20.3 93.2 20.5 93.2 20.5 91.8 20.0 85.2 18.2
21.0 15.0 93.2 20.2 93.2 20.5 93.2 20.6 93.2 20.3 91.8 19.4 85.2 17.9
-14.7 -15.0 49.3 15.0 49.3 15.7 49.3 16.3 49.3 16.6 49.3 16.9 49.3 17.6
-12.6 -13.0 52.3 15.7 52.3 16.3 52.3 16.9 52.3 17.3 52.3 17.5 52.3 18.1
-10.5 -11.0 55.4 16.3 55.4 16.8 55.4 17.5 55.4 17.8 55.4 18.0 55.4 18.6
-9.5 -10.0 57.1 16.6 57.1 17.1 57.1 17.6 57.1 18.0 57.1 18.3 57.1 18.8
-8.5 -9.1 58.4 16.8 58.4 17.3 58.4 18.0 58.4 18.1 58.4 18.5 58.4 19.0
-7.0 -7.6 60.7 17.1 60.7 17.6 60.7 18.1 60.7 18.5 60.7 18.8 60.7 19.3
-5.0 -5.6 63.7 17.6 63.7 18.1 63.7 18.6 63.7 18.8 63.7 19.1 63.7 19.6
-3.0 -3.7 66.6 18.0 66.6 18.5 66.6 19.0 66.6 19.1 66.6 19.5 66.6 19.8
capacity
factor
outdoor temp.
AV26NMVERA heating mode
