AV32NMVERA heating mode
indoor temp. (℃DB)
16.0 24.018.0 20.0 21.0 22.0
-5.0 -5.6 67.6 21.9 63.6 20.6 60.0 19.2 58.0 18.6 56.2 17.9 52.2 16.6
-3.0 -3.7 67.6 20.9 63.6 19.6 60.0 18.3 58.0 17.7 56.2 17.1 52.2 15.9
0.0 -0.7 67.6 19.4 63.6 18.2 60.0 17.0 58.0 16.5 56.2 15.9 52.2 14.8
3.0 2.2 67.6 18.1 63.6 17.0 60.0 16.0 58.0 15.4 56.2 14.9 52.2 13.9
5.0 4.1 67.6 17.4 63.6 16.4 60.0 15.3 58.0 14.8 56.2 14.4 52.2 13.4
7.0 6.0 67.6 16.7 63.6 15.7 60.0 14.8 58.0 14.3 56.2 13.8 52.2 12.9
9.0 7.9 67.6 16.1 63.6 15.2 60.0 14.2 58.0 13.8 56.2 13.4 52.2 12.5
11.0 9.8 67.6 15.5 63.6 14.6 60.0 13.8 58.0 13.3 56.2 12.9 52.2 12.1
13.0 11.8 67.6 15.0 63.6 14.1 60.0 13.3 58.0 12.9 56.2 12.5 52.2 11.7
15.0 13.7 67.6 14.5 63.6 13.7 60.0 12.9 58.0 12.5 56.2 12.1 52.2 11.3
19.0 14.2 67.6 14.1 63.6 13.0 60.0 12.5 58.0 12.1 56.2 11.6 52.2 10.8
21.0 15.0 67.6 13.5 63.6 12.7 60.0 12.0 58.0 11.7 56.2 11.3 52.2 10.4
-14.7 -15.0 56.4 24.0 53.0 22.5 50.0 21.1 48.4 20.3 46.8 19.6 43.4 18.1
-12.6 -13.0 56.4 22.5 53.0 21.1 50.0 19.6 48.4 19.0 46.8 18.3 43.4 17.0
-10.5 -11.0 56.4 21.1 53.0 19.7 50.0 18.4 48.4 17.8 46.8 17.2 43.4 16.0
-9.5 -10.0 56.4 20.4 53.0 19.1 50.0 17.9 48.4 17.3 46.8 16.7 43.4 15.5
-8.5 -9.1 56.4 19.9 53.0 18.6 50.0 17.5 48.4 16.9 46.8 16.3 43.4 15.1
-7.0 -7.6 56.4 19.0 53.0 17.9 50.0 16.7 48.4 16.2 46.8 15.6 43.4 14.6
-5.0 -5.6 56.4 18.0 53.0 16.9 50.0 15.9 48.4 15.4 46.8 14.8 43.4 13.8
-3.0 -3.7 56.4 17.2 53.0 16.1 50.0 15.2 48.4 14.7 46.8 14.2 43.4 13.2
0.0 -0.7 56.4 16.0 53.0 15.1 50.0 14.1 48.4 13.7 46.8 13.3 43.4 12.4
3.0 2.2 56.4 15.0 53.0 14.1 50.0 13.3 48.4 12.9 46.8 12.5 43.4 11.7
5.0 4.1 56.4 14.4 53.0 13.6 50.0 12.8 48.4 12.4 46.8 12.2 43.4 11.3
7.0 6.0 56.4 13.9 53.0 13.1 50.0 12.4 48.4 12.0 46.8 11.6 43.4 10.9
9.0 7.9 56.4 13.4 53.0 12.7 50.0 12.0 48.4 11.6 46.8 11.2 43.4 10.5
11.0 9.8 56.4 13.0 53.0 12.3 50.0 11.6 48.4 11.2 46.8 10.9 43.4 10.2
13.0 11.8 56.4 12.6 53.0 11.9 50.0 11.2 48.4 10.9 46.8 10.5 43.4 9.9
15.0 13.7 56.4 12.2 53.0 11.5 50.0 10.9 48.4 10.6 46.8 10.2 43.4 9.6
19.0 14.2 56.4 11.8 53.0 11.1 50.0 10.5 48.4 10.1 46.8 9.9 43.4 9.2
21.0 15.0 56.4 11.0 53.0 10.8 50.0 10.2 48.4 9.7 46.8 9.5 43.4 8.8
TC: total capacity; PI: power input
