Haier AV26NMVERA [308/531] Av10nmvera heating mode
![Haier AV26NMVERA [308/531] Av10nmvera heating mode](/views2/1816541/page308/bg134.png)
TC PI TC PI TC PI TC PI TC PI TC PI
℃DB ℃WB KW KW KW KW KW KW KW KW KW KW KW KW
capacity
factor
outdoor temp.
AV10NMVERA heating mode
indoor temp. (℃DB)
16.0 24.018.0 20.0 21.0 22.0
5.0 4.1 30.5 7.84 30.3 7.91 28.3 7.39 27.3 7.13 26.5 6.81 24.6 6.32
7.0 6.0 31.5 7.91 30.3 7.58 28.3 7.07 27.3 6.81 26.5 6.56 24.6 6.07
9.0 7.9 32.0 7.78 30.3 7.26 28.3 6.81 27.3 6.56 26.5 6.31 24.6 5.84
11.0 9.8 32.0 7.46 30.3 7.01 28.3 6.56 27.3 6.30 26.5 6.07 24.6 5.63
13.0 11.8 32.0 7.20 30.3 6.75 28.3 6.28 27.3 6.06 26.5 5.85 24.6 5.42
15.0 13.7 32.0 6.94 30.3 6.49 28.3 6.06 27.3 5.86 26.5 5.65 24.6 5.24
19.0 14.2 32.0 6.77 30.3 6.31 28.3 5.87 27.3 5.68 26.5 5.45 24.6 5.05
21.0 15.0 32.0 6.52 30.3 6.07 28.3 5.76 27.3 5.49 26.5 5.25 24.6 4.84
-14.7 -15.0 20.0 6.94 20.0 7.13 20.0 7.33 20.0 7.39 20.0 7.46 20.0 7.65
-12.6 -13.0 21.1 7.13 21.1 7.26 21.1 7.46 21.1 7.52 21.1 7.65 21.1 7.78
-10.5 -11.0 22.2 7.26 22.2 7.46 22.2 7.58 22.2 7.71 22.2 7.78 22.0 7.91
-9.5 -10.0 22.8 7.39 22.8 7.52 22.8 7.65 22.8 7.78 22.8 7.84 22.0 7.97
-8.5 -9.1 23.3 7.46 23.3 7.58 23.3 7.71 23.3 7.84 23.3 7.91 22.0 7.84
-7.0 -7.6 24.2 7.52 24.2 7.65 24.1 7.84 24.1 7.91 23.6 7.97 22.0 7.46
-5.0 -5.6 25.2 7.65 25.2 7.78 25.2 7.91 24.3 7.97 23.6 7.65 22.0 7.07
-3.0 -3.7 26.2 7.78 26.2 7.91 25.2 7.84 24.3 7.52 23.6 7.26 22.0 6.68
0.0 -0.7 27.8 7.91 26.8 7.78 25.2 7.26 24.3 7.01 23.6 6.68 22.0 6.21
3.0 2.2 28.3 7.71 26.8 7.26 25.2 6.75 24.3 6.49 23.6 6.27 22.0 5.81
5.0 4.1 28.3 7.39 26.8 6.94 25.2 6.49 24.3 6.23 23.6 6.01 22.0 5.57
7.0 6.0 28.3 7.07 26.8 6.62 25.2 6.20 24.3 5.99 23.6 5.78 22.0 5.36
9.0 7.9 28.3 6.81 26.8 6.38 25.2 5.96 24.3 5.76 23.6 5.56 22.0 5.16
11.0 9.8 28.3 6.56 26.8 6.14 25.2 5.75 24.3 5.55 23.6 5.36 22.0 4.97
13.0 11.8 28.3 6.31 26.8 5.91 25.2 5.53 24.3 5.35 23.6 5.16 22.0 4.80
15.0 13.7 28.3 6.09 26.8 5.66 25.2 5.35 24.3 5.17 23.6 4.99 22.0 4.65
19.0 14.2 28.3 5.88 26.8 5.56 25.2 5.13 24.3 4.98 23.6 4.78 22.0 4.53
21.0 15.0 28.3 5.71 26.8 5.32 25.2 5.00 24.3 4.82 23.6 4.62 22.0 4.29
-14.7 -15.0 20.0 7.33 20.0 7.52 20.0 7.65 20.0 7.71 20.0 7.78 19.2 7.97
-12.6 -13.0 21.1 7.52 21.1 7.65 21.1 7.78 21.1 7.84 20.6 7.97 19.2 7.65
-10.5 -11.0 22.2 7.65 22.2 7.78 22.1 7.91 21.3 7.97 20.6 7.71 19.2 7.13
-9.5 -10.0 22.8 7.71 22.8 7.84 22.1 7.97 21.3 7.78 20.6 7.46 19.2 6.88
-8.5 -9.1 23.3 7.78 23.3 7.91 22.1 7.84 21.3 7.58 20.6 7.26 19.2 6.75
-7.0 -7.6 24.1 7.84 23.5 7.97 22.1 7.52 21.3 7.20 20.6 6.94 19.2 6.43
-5.0 -5.6 24.9 7.97 23.5 7.58 22.1 7.07 21.3 6.81 20.6 6.56 19.2 6.09
-3.0 -3.7 24.9 7.71 23.5 7.20 22.1 6.75 21.3 6.49 20.6 6.25 19.2 5.79
0.0 -0.7 24.9 7.13 23.5 6.68 22.1 6.24 21.3 6.02 20.6 5.80 19.2 5.39
3.0 2.2 24.9 6.68 23.5 6.24 22.1 5.83 21.3 5.63 20.6 5.44 19.2 5.05
5.0 4.1 24.9 6.38 23.5 5.98 22.1 5.60 21.3 5.41 20.6 5.22 19.2 4.85
7.0 6.0 24.9 6.12 23.5 5.75 22.1 5.38 21.3 5.20 20.6 5.02 19.2 4.67
9.0 7.9 24.9 5.89 23.5 5.53 22.1 5.18 21.3 5.01 20.6 4.84 19.2 4.51
11.0 9.8 24.9 5.67 23.5 5.33 22.1 5.00 21.3 4.83 20.6 4.63 19.2 4.35
13.0 11.8 24.9 5.46 23.5 5.14 22.1 4.82 21.3 4.67 20.6 4.51 19.2 4.20
80
70
308
