1. Features
3-dimensional air flow
We call this kind of wall mounted unit as V-
appearance unit, and it has the 3-
dimensional air flow technology. The air
will be distributed horizontally and
vertically via the horizontal flap and the
vertical flap, which avoids the air throwing
at the person directly. Much more
comfortable.
AS072MVERA
AS092MVERA
AS122MVERA
AS162MVERA
AS182MVERA
Anti-bacteria filter
The high efficiency filter can prevent the
dust and the horrible smell into the room,
and be with anti-bacteria function, much
healthier.
LCD display
Attractive new appearance design with
blue LCD display. It makes the stylish air
conditioner more beautiful and
distinguished.
