Duct installation:
HRV
aluminum foil
gradient more than 1/30
Maintenance space:
Install the two outdoor ducts at a certain gradient(no less than 1/30) to avoid the water flowing
backward. Meanwhile the three ducts(two outdoor ducts, one indoor duct) all need the heat insulation
material against the dew.
Installation distance between air discharging hole and air inelt hole should be 3 times longer than
duct.
600
maintenance
space
