AB092MCERA
AB122MCERA
AB162MCERA
PANEL:
PB-700IB
AB182MEERA
AB242MEERA
AB282MEERA
AB302MEERA
AB382MEERA
AB482MEERA
PANEL:
PB-950IB
1. Features
Totally new appearance design
AB09~AB16 adopt the 700*700 panel with
600*600 unit body. And AB18~AB48 use the
same panel, more easy installation and design.
Compact and unitary appearance to get perfect
harmonized indoor decor.
Thanks for the light unit weight,
suspension is convenient and easy
Low operation noise level
model
noise level
H/M/L
AB09 AB12 AB16 AB18 AB24 AB28 AB30 AB38 AB48
32/30/29 32/30/29 33/30/29
34/32/30 35/34/31 37/35/31 37/35/31 37/35/31 42/39/35
Built-in high head drainage
A standard built-in drain pump can realize up to 600mm drainage head, which creates the
ideal solution for perfect water drainage.
Fresh air inlet
Pre-set fresh air inelt hole, which can lead the fresh air from outside into indoor, greatly
improves indoor air quality.
Long life filter is standard part with the unit.
