TC PI TC PI TC PI TC PI TC PI TC PI
℃DB ℃WB
KW KW KW KW KW KW KW KW KW KW KW KW
-14.7 -15.0 74.5 19.9 74.5 21.0 74.5 22.1 74.4 22.7 74.4 23.3 74.4 24.4
-12.6 -13.0 78.7 21.0 78.7 22.1 78.7 23.1 78.7 23.7 78.7 24.2 78.7 25.3
-10.5 -11.0 83.1 22.0 83.1 23.0 83.1 24.0 83.1 24.5 83.1 25.0 83.1 26.0
-9.5 -10.0 86.0 22.5 86.0 23.4 86.0 24.4 86.0 25.0 86.0 25.4 86.0 26.4
-8.5 -9.1 88.4 22.9 88.4 23.8 88.4 24.8 88.4 25.3 88.4 25.7 88.4 26.7
-7.0 -7.6 92.1 23.5 92.1 24.4 92.1 25.4 92.1 25.9 92.1 26.2 92.1 27.2
-5.0 -5.6 96.5 24.2 96.5 25.1 96.5 25.9 96.5 26.4 96.5 26.9 96.5 27.7
-3.0 -3.7 100.7 24.9 100.7 25.7 100.7 26.6 100.7 27.1 100.7 27.4 100.7 28.4
0.0 -0.7 107.0 25.8 107.0 26.6 107.0 27.4 107.0 27.8 107.0 28.1 107.0 28.9
3.0 2.2 112.6 26.6 112.6 27.3 112.6 28.1 112.6 28.4 112.6 28.8 112.6 29.6
5.0 4.1 117.2 27.1 117.2 27.8 117.2 28.6 117.2 28.8 117.2 29.3 117.2 29.9
7.0 6.0 121.5 27.6 121.5 28.3 121.5 28.8 121.5 29.3 121.5 29.6 121.5 30.3
9.0 7.9 125.9 27.8 125.8 28.6 125.8 29.3 125.8 29.6 125.8 29.9 125.8 30.6
11.0 9.8 130.5 28.3 130.5 28.8 130.5 29.6 130.5 29.9 130.5 30.3 130.5 30.8
13.0 11.8 134.3 28.6 134.3 29.3 134.3 29.9 134.3 30.3 134.3 30.6 134.3 31.1
15.0 13.7 138.4 29.0 138.3 29.5 138.3 30.1 138.3 30.6 138.3 30.8 137.4 31.0
19.0 14.2 138.4 29.3 138.3 29.9 138.3 30.4 138.3 30.8 138.3 31.1 137.4 30.3
21.0 15.0 138.4 29.7 138.3 30.3 138.3 30.7 138.3 31.0 138.3 30.9 137.4 29.7
-14.7 -15.0 74.5 21.4 74.4 22.4 74.4 23.5 74.4 24.0 74.4 24.5 74.4 25.6
-12.6 -13.0 78.7 22.4 78.7 23.4 78.7 24.4 78.7 24.9 78.7 25.4 78.7 26.5
-10.5 -11.0 83.1 23.4 83.1 24.3 83.1 25.2 83.1 25.7 83.1 26.2 83.1 27.2
-9.5 -10.0 86.0 23.8 86.0 24.7 86.0 25.7 86.0 26.0 86.0 26.5 86.0 27.5
-8.5 -9.1 88.4 24.2 88.4 25.0 88.4 25.9 88.4 26.4 88.4 26.9 88.4 27.7
-7.0 -7.6 92.1 24.7 92.1 25.6 92.1 26.4 92.1 26.9 92.1 27.2 92.1 28.2
-5.0 -5.6 96.5 25.4 96.5 26.2 96.5 27.1 96.5 27.4 96.5 27.9 96.5 28.6
-3.0 -3.7 100.7 26.1 100.7 26.9 100.7 27.6 100.7 27.9 100.7 28.4 100.7 29.2
0.0 -0.7 107.0 26.9 107.0 27.6 107.0 28.4 107.0 28.6 107.0 29.1 107.0 29.3
3.0 2.2 112.6 27.6 112.6 28.3 112.6 29.1 112.6 29.3 112.6 29.6 112.6 30.4
5.0 4.1 117.2 28.1 117.2 28.6 117.2 29.3 117.2 29.6 117.2 30.0 117.2 30.7
7.0 6.0 121.5 28.4 121.5 29.1 121.5 29.8 121.5 30.0 121.5 30.3 121.5 31.1
9.0 7.9 125.8 28.8 125.8 29.3 125.8 30.0 125.8 30.3 125.8 30.6 126.1 31.4
11.0 9.8 130.5 29.1 130.5 29.8 130.5 30.3 130.5 30.6 130.5 30.8 127.0 30.5
13.0 11.8 134.3 29.5 134.3 30.0 134.3 30.6 134.3 30.8 134.3 31.3 127.0 29.4
15.0 13.7 138.3 29.8 138.3 30.3 138.3 30.8 138.3 31.1 136.7 30.7 127.0 28.2
19.0 14.2 138.3 30.2 138.3 30.7 138.3 31.0 138.3 30.8 136.7 30.1 127.0 27.7
21.0 15.0 138.3 30.6 138.3 30.7 138.3 30.8 138.3 30.4 136.7 29.1 127.0 27.2
-14.7 -15.0 74.4 22.9 74.4 23.9 74.4 24.8 74.4 25.3 74.4 25.8 74.4 26.8
-12.6 -13.0 78.7 23.9 78.7 24.8 78.7 25.7 78.7 26.2 78.7 26.5 78.7 27.5
-10.5 -11.0 83.1 24.7 83.1 25.5 83.1 26.5 83.1 26.9 83.1 27.2 83.1 28.2
-9.5 -10.0 86.0 25.1 86.0 26.0 86.0 26.7 86.0 27.2 86.0 27.7 86.0 28.5
-8.5 -9.1 88.4 25.5 88.4 26.2 88.4 27.2 88.4 27.5 88.4 27.9 88.4 28.7
-7.0 -7.6 92.1 25.9 92.1 26.7 92.1 27.5 92.1 27.9 92.1 28.4 92.1 29.2
-5.0 -5.6 96.5 26.6 96.5 27.4 96.5 28.1 96.5 28.5 96.5 28.9 96.5 29.6
-3.0 -3.7 100.7 27.2 100.7 27.9 100.7 28.6 100.7 28.9 100.7 29.4 100.7 30.0
0.0 -0.7 107.0 27.9 106.9 28.6 106.9 29.3 106.9 29.6 106.9 29.9 106.9 30.7
3.0 2.2 112.6 28.6 112.6 29.3 112.6 29.9 112.6 30.1 112.6 30.6 112.6 31.1
5.0 4.1 117.2 29.1 117.2 29.6 117.2 30.1 117.2 30.6 117.2 30.8 116.5 31.1
7.0 6.0 121.5 29.3 121.5 29.9 121.5 30.6 121.5 30.8 121.5 31.1 116.5 29.8
AV38NMVERA heating mode
capacity
factor
outdoor temp.
indoor temp. (℃DB)
16.0 18.0 20.0 21.0 22.0 24.0
130
120
110
361
