Accessories
113
Figure 87 Install Device
Device Removal
To remove the EC30 from the adapter, push the release tab and pull the bottom of the EC30 away from the
adapter.
Figure 88 EC30 Removal
Strap Installation
The user can remove the strap for replacement or cleaning and then re-install a new strap.
1. Remove existing strap.
2. Feed the ends of the strap through the slots with hook material positioned as shown below.
Release Lever
