Zebra EC30 EC300K-1SA2AA6 [69/127] Applications

Applications

Enabling PTT Communication

1. Swipe up from the bottom of the Home screen and touch .

2. Slide the Enable/Disable Switch to the ON position. The button changes to ON.

Selecting a Talk Group

One of 32 Talk Groups can be selected by PTT Express users. However, only one talk group may be enabled

at a time on the device. Touch one of the 32 Talk Groups. The selected Talk Group is highlighted.

PTT Communication

NOTE: This section describes the default PTT Express client configuration. Refer to the PTT Express V1.2 User Guide for

detailed information on using the client.

PTT communication may be established as a Group Call. When PTT Express is enabled, the PTT button on

the left side of the device is assigned for PTT communication. When the Wired Headset is used, Group Calls

can also be initiated using the headset Talk button. When not using a headset, optimal placement of EC30

microphone is two and six inches from your mouth.

NOTE: When using a wired headset, use only Zebra approved wired headsets with a PTT button.

Figure 38 PTT Button

The PTT Express Voice client is enabled and muted.

The PTT Express Voice client is enabled but it is not able to communicate due to a VoIP

telephony call in progress.

Table 12 PTT Express Icon Descriptions (Continued)

Status Icon Description

PTT Button

Microphone

Speaker
