Zebra EC30 EC300K-1SA2AA6 [123/127] Technical specifications
![Zebra EC30 EC300K-1SA2AA6 [123/127] Technical specifications](/views2/1834619/page123/bg7b.png)
Technical Specifications
123
Bluetooth Class 2, Bluetooth v5.0 (Bluetooth Smart technology); Bluetooth
Wideband support HFPv1.6; Bluetooth v5.2 Low Energy (LE)
Data Capture Specifications
Scanning SE2100 imager (1D and 2D) with LED aimer.
2D Imager Engine Specifications
Field of View Horizontal - 41.5°
Vertical - 31.7°
Image Resolution 640 horizontal X 480 vertical pixels
Roll 360°
Pitch Angle +/- 60° from normal
Skew Tolerance +/- 60° from normal
Ambient Light Sunlight: 10,000 ft. candles (107,639 lux)
Focal Distance From front of engine: 10.7 cm (4.2 in.)
Illumination System LEDs: Ultra white
Pattern Angle: 42° horizontal, 32.0° vertical at 50% intensity
Table 17 Data Capture Supported Symbologies
Item Description
1D Bar Codes Code 128, EAN-8, EAN-13, GS1 DataBar Expanded, GS1 128,
GS1 DataBar Coupon, UPCA, Interleaved 2 of 5, UPC Coupon
Code
2D Bar Codes PDF-417, QR Code
Table 16 EC30 Technical Specifications
Item Description
