Data Capture

3. On the device swipe up from the bottom of the Home screen and touch .

Figure 57 Bluetooth Pairing Utility

4. Using the scanner, scan the barcode on the screen.

The scanner emits a high/low/high/low beeps. The Scan LED flashes green indicating that the scanner is

attempting to establish connection with the device. When connection is established, the Scan LED turns off

and the scanner emits one string of low/high beeps.

5. On the device touch .

Pairing Using Bluetooth Human Interface Device

To pair the scanner with the device using HID:

1. Remove the battery from the scanner.

2. Replace the battery.

3. After the scanner reboots, scan the barcode below to place the scanner in HID mode.

Figure 58 Bluetooth HID Classic Barcode

4. On the device, swipe down from the Status bar to open the Quick Access panel and then touch .

5. Touch Bluetooth.

6. Touch Pair new device. The device begins searching for discoverable Bluetooth devices in the area and

displays them under Available devices.

7. Scroll through the list and select XXXXX xxxxxx, where XXXXX is the scanner and xxxxxx is the serial

number.

The device connects to the scanner, the scanner beeps once and Connected appears below the device
