Citizen CL-E303 [102/154] Control characters are coded into code subset a see the control characters are coded into code subset a see the character input reference table below

1-101

[Example] The TEST bar code is first printed with code subset B,

and then 123 bar code with code subset A. Data is transmitted in

the order of B, TEST, 2-character &F, and 123.

Input code: BTEST&F123

Bar code data: <CODEB>TEST<CODEA>123

Control code

Control characters are coded into code subset A. See the

character input reference table below.

Control

code

Input

character

Control

code

Input

character

Control

code

Input

character

NUL ` VT k SYN v

SOH a FF l ETB w

STX b CR m CAN x

ETX c SO n EM y

EOT d SI o SUB z

ENQ e DLE p ESC {

ACK f DC1 q FS |

BEL g DC2 r GS }

BS h DC3 s RS ~

HT i DC4 t US DEL

LF j NAK u
