1-29
Extension system command (printer settings)
Code
[02] Kdabc
Transmission
data
Printer setting paramete
r
a Hex notation for the following bit settings
bit 0-2 baud rate
case bit 4 = 0
0=9600*, 1=600, 2=2400, 3=4800, 5=300,
6=1200, 7=9600 test mode
case bit 4 = 1
0=115200, 1=57600, 2=38400, 3= none, 5=none,
6= none 7= none
bit 3 character length
0=8 bits*, 1=7 bits
bit 4 Extended baud rate
0=OFF*, 1=ON
bit 5 (not used) always 0
bit 6 (fixed) always 1
bit 7 (fixed) always 0
b Hex notation for the following bit settings
bit 0 printing method
0=thermal, 1=thermal transfer*
bit 1 peeling sensor
0=OFF*, 1=ON
bit 2 (not used) always 0
bit 3 auto-cutter
0=OFF*, 1=ON
bit 4-5 (not used) always 0
bit 6 (fixed) always 1
bit 7 (fixed) always 0
c Hex notation for the following bit settings
bit 0-1 type of paper
0=transparent*, 1=reflective, 2=continuous (3 inches)
bit 2-5 (not used) always 0
bit 6 (fixed) always 1
bit 7 (fixed) always 0
(*: factory setting)
Function
Provides various printer settings.
Caution
This setting is stored even when the power is turned off.
Example
[02]KD@A@[0D]
@: 9600 baud, 8-bit length, no parity
A: thermal, no peeling sensor, no auto-cutter
@: transparent paper
