1-140
(continued)
System level commands Models
521
621
9001
9301
8301
STX Mnnnn Setting max. label length (detection miss
checking)
Y Y
m Changing units from inch system to metric system Y Y
n Changing units from metric system to inch system Y Y
Onnnn Setting printing position (form offset) Y Y
o Paper cut Y Y
P Setting dump mode on Y Y
p Pause in occasional execution Y Y
Q Clearing all memory modules Y Y
q Clearing memory module contents q (A/B) Y Y
r Selecting reflective (black line) sensor for paper
position detection
Y Y
Sa Setting paper feed speed Y Y
s Setting one page edit mode (single buffer) Y Y
T Printing quality test pattern Y Y
Unnaa Rewriting specified format register contents Y Y
V
Setting memory switch contents
Y Y
v
Version number transmission request
Y Y
W
Information-in-memory-module transmission
request
Y Y
w
Testing flash memory
Y N/A
Xa
Selecting default module (A/B)
Y Y
xntname
Clearing memory module contents (in file
units)
Y Y
Y
Sensor level issued to port
N/A N/A
yS
TrueType fonts Symbol Set Selection
Y Y
Z
Test print for printer status
Y Y
z
Packing memory module contents
N/A N/A
"ESC"+G
Select Command Set
Y Y
"ESC"+M
Setting Printing Method
Y N/A
"ESC"+S Paper detection sensor voltage transmission
request
N/A N/A
"ESC"+T Head disconnection detection Y Y
"ESC"+t Setting ejection (tear-off) Y Y
“ESC”+wnnnn Setting label width Y Y
