Citizen CL-E303 [32/154] Specifying printing contents setting start

1-31

Specifying printing contents setting start

Code

[02] L

Function

With this command input, printer enters the label format mode and

waits for input of printing contents definition and label format

commands until it receives "E" "s" or "X" code.

Example

Input data below represents that label format command input is

started, data "ABC" is defined as printing contents, label format

command input is completed, and label printing command "E" is

entered.

Input data

[02] n Sets units to inch

[02] L Starts label format mode

D22 Sets pixel size

190001001000050ABC Sets character data "ABC" with smooth

font 48pt

E Ends label format mode and prints

Direction of feed
