Citizen CL-E303 [23/154] Setting peeling cutting position
![Citizen CL-E303 [23/154] Setting peeling cutting position](/views2/1842788/page23/bg17.png)
1-22
Setting peeling (cutting) position
Code
[02] f nnn
Units
0.01 inch (0.1mm)
Setting
nnn 3-digit data
Initial value and its set range vary depending on the command setting.
Inch s
y
stem Metric s
y
stem
Initial
value
Minimum
value
Max
value
Initial
value
Minimum
value
Max
value
DMI / DMW
Normal
000 000 200 000 000 508
Cutte
r
100 000 200 254 000 508
Peel
050 000 150 127 000 381
Tear Off
070 000 170 178 000 432
DM4 / DM8
Normal
220 220 420 559 559 1067*
Cutte
r
340 240 440 864 610 1118*
Peel
270 220 370 686 559 940
Tear Off
290 220 390 737 559 991
DPP
Normal
110 110 310 279 279 787
Cutte
r
230 130 330 584 330 838
Peel
146 96 246 371 244 625
Tear Off
166 96 266 422 244 676
*In setting 4-digit value, use [02] Kf command.
Function
With the setting above, the distance between paper sensor and
cutter or peeler can be specified.
When nnn is small, the amount of feed is small, so printed label will
be cut.
When nnn is appropriate, the label is fed the required amount, then
cut at the paper gap.
When nnn is large, the amount of feed is large, so the next printing
label will be cut.
Caution
If value out of range is specified, the command parameter will be
ignored.
If optional functions such as cutter, peeler and ejection are turned
on from the control panel, their initialization values will be set
automatically. These initialization values, however, vary depending
on the specifications of each option. For details, see the instruction
manuals of each option.
Once this command was set, auto-setting function is stopped due to
priority for user's specification. Do not set this command if not
necessary.
