7
EN
Do not use the machine if the mains cable or
the mains plug is damaged.
Only use extension cables that are suitable for
the power rating of the machine with a minimum
thickness of 1.5 mm2. If you use a extension
cable reel, always fully unroll the cable.
Technical data
AGM1086 AGM1087
Mains voltage 230 V~
Mains frequency 50 Hz
Power input 500 W 850 W
No-load speed 11,000/min
Grinding disc
Diameter 115 mm 125 mm
Bore 22.2 mm
Spindle thread M14
Weight 1.69 kg 1.94 kg
Noise and vibration
Sound pressure (Lpa) (K=3dB) 70 dB(A) 89.9 dB(A)
Acoustic power (Lwa) (K=3dB) 80 dB(A) 100.9 dB(A)
Vibration (K=1.5 m/s
2
) 2.5 m/s
2
5.587 m/s
2
Vibration level
The vibration emission level stated in this instruction
manual has been measured in accordance with
a standardised test given in EN 60745; it may be
used to compare one tool with another and as a
preliminary assessment of exposure to vibration
when using the tool for the applications mentioned
- using the tool for different applications, or with
different or poorly maintainted accessories, may
significantly increase the exposure level
- the times when the tool is switched off or when it
is running but not actually doing the job, may signifi
cantly reduce the exposure level
Protect yourself against the effects of vibration by
maintaining the tool and its accessories, keeping
your hands warm, and organizing your work patterns
Wear hearing protection.
DESCRIPTION (FIG. A)
Your angle grinder has been designed for grinding
and cutting masonry and steel.
1. On/off switch
2. Spindle lock button
3. Spindle
4. Guard
5. Main grip
6. Auxiliary grip
ASSEMBLY
Before assembly, always switch off the
machine and remove the mains plug from
the mains.
Mounting and removing the guard & grinding
disc (fig. B)
Do not use the machine without the guard.
Mounting
Place the machine on a table with the spindle
(3) facing upwards.
Keep the spindle lock button (2) pressed and
remove the flange (7) using the flange key (8).
If necessary, remove the grinding disc (9).
Remove the flange (10).
Mount the guard (4). Secure the guard (4) by
tightening the screw (11) and the nut (12).
Mount the flange (10).
If necessary, mount the grinding disc (9).
Keep the spindle lock button (2) pressed and
mount the flange (7) using the flange key (8).
Removing
Place the machine on a table with the spindle
(3) facing upwards.
Keep the spindle lock button (2) pressed and
remove the flange (7) using the flange key (8).
If necessary, remove the grinding disc (9).
Remove the flange (10).
Remove the guard (4) by loosening the screw
(11) and the nut (12).
Mount the flange (10).
If necessary, mount the grinding disc (9).
Keep the spindle lock button (2) pressed and
mount the flange (7) using the flange key (8).
Mounting and removing the auxiliary grip
(fig. C)
Mounting
Tighten the auxiliary grip (6) into one of the
mounting holes (13).
