FERM PDM1051 [5/104] Assembly
![FERM PDM1051 [5/104] Assembly](/views2/1858311/page5/bg5.png)
5
EN
• Make sure that the maximum speed for the
accessory is larger than or the same as the
maximum speed of the machine. Refer to the
rating plate on the machine.
• Before use, remove all nails and other metal
objects from the workpiece.
• Make sure that the workpiece is properly
supported or fixed.
• Keep your hands away from the workpiece
during use.
• Never put the machine down on a table or a
workbench before it has been switched off.
Electrical safety
Always check that the voltage of the
power supply corresponds to the voltage
on the rating plate.
• Do not use the machine if the mains cable or
the mains plug is damaged.
• Only use extension cables that are suitable
for the power rating of the machine with a
minimum thickness of 1.5 mm
2
. If you use a
extension cable reel, always fully unroll the
cable.
TECHNICAL SPECIFICATIONS
Mains voltage 220-240 V~
Mains frequency 50 Hz
Power input 550 W
No-load speed 0 - 3.000 /min
Impact rate 0 - 48.000 /min
Protection class IP 20
Weight 1.88 kg
Max. drill diameter
Wood 25 mm
Concrete 13 mm
Steel 10 mm
Noise values
Sound pressure (L
PA
) 94 dB(A)
Acoustic power (L
WA
) 105 dB(A)
Uncertainty (K) 3 dB(A)
Vibration values
Impact drilling into concrete, a
h,ID
7.1 m/s
2
Drilling into metal, a
h,D
2.87 m/s
2
Uncertainty (K) 1.5 m/s
2
Wear hearing protection.
Vibration level
The vibration emission level stated in this
instruction manual has been measured in
accordance with a standardised test given in
EN 60745; it may be used to compare one tool
with another and as a preliminary assessment of
exposure to vibration when using the tool for the
applications mentioned.
- using the tool for different applications, or with
different or poorly maintainted accessories,
may significantly increase the exposure level
- the times when the tool is switched off or when
it is running but not actually doing the job, may
significantly reduce the exposure level
Protect yourself against the effects of vibration by
maintaining the tool and its accessories, keeping
your hands warm, and organizing your work
patterns.
DESCRIPTION (FIG. A)
Your impact drill has been designed for drilling
holes in wood, metal and plastics and for hammer
drilling in brick and concrete.
1. On/off switch
2. Lock-on button
3. Speed adjustment wheel
4. Forward/reverse switch
5. Switch for drilling / hammer drilling
6. Chuck
7. Main grip
8. Auxiliary grip
9. Depth stop
10. Rear sleeve
11. Front sleeve
ASSEMBLY
Before assembly, always switch off the
machine and remove the mains plug from
the mains.
