7
EN
• Place the saw blade in the blade holder.
• Let go of the clamping ring.
• Make sure when changing the saw blade that
the blade holder is free of material debris
(such as splinters of wood or metal).
• Before use, always check that the saw blade is
securely xed.
Removing the saw blade
• Turn the clamping ring of the saw blade holder
as far to the left as possible and hold it there.
• Remove the saw blade from its holder.
• Let go of the clamping ring.
Mounting and removing the parallel guide
(g. C)
The parallel guide is used for sawing along edges
at a maximum distance of 16 cm.
Mounting
• Slacken the Allen screws (8) using the Allen
key (11).
• Insert the parallel guide (16) into the saw shoe
(7).
• Set the parallel guide (16) to the required
position.
• Tighten the Allen screws (8) using the Allen
key (11).
Removing
• Slacken the Allen screws (8) using the Allen
key (11).
• Remove the parallel guide (16) from the saw
shoe (7).
• Tighten the Allen screws (8) using the Allen
key (11).
USE
Switching on and off (g. A)
● To switch on the machine, press the on/off
switch (1).
● To switch the machine to continuous mode,
keep the on/off switch (1) pressed and
simultaneously press the lock-on button (2).
● To switch off the machine, release the on/off
switch (1).
Setting the sawing speed (g. A)
The speed adjustment wheel is used for setting
the sawing speed. The speed adjustment wheel
can be set to 6 positions. The ideal sawing speed
depends on the prole and the teeth of the saw
blade and on the material to be worked.
2
Do not set the sawing speed during use.
● Turn the speed adjustment wheel (3) to the
required position.
● For hard materials, use a saw blade with ne
teeth and select a lower speed.
● For soft materials, use a saw blade with
coarse teeth and select a higher speed.
Setting the mitre angle (g. D)
The mitre angle is variable between -45° and
+45°.
2
Do not set the mitre angle during use.
● Slacken the Allen screws (17) using the Allen
key (11).
● Tilt the saw shoe (7) to the required position.
● Tighten the Allen screws (17) using the Allen
key (11).
Using the pendulum action switch (g. A)
The pendulum action switch is used to set the
way in which the teeth of the saw blade grip the
material. The pendulum action switch can be set
to 4 positions.
2
Do not set the pendulum position during
use.
● Turn the pendulum action switch (4) to
required position according to the material to
be worked. Refer to the table below to select
the required position.
Material Pendulum position
Wood 1-3
Plastics 1
Aluminium 0-1
Steel 0
Ceramics 0
Rubber 0
Dust extraction (g. E)
● Insert the dust extraction adapter (18) into the
dust extraction connection (9).
● Connect the hose of a vacuum cleaner to the
dust extraction adapter (18).
Hints for optimum use
● Clamp the workpiece. Use a clamping device
for small workpieces.
