Kickback is usually caused by:
- unintentionally touching hard objects or
materials with the rotating saw blade;
- a blunt saw blade;
- a saw blade that is not properly mounted;
- sawing into a previous cut;
- a lack of attention to the operation;
- an instable stance.
ELECTRICAL SAFETY
3
Always check that the voltage of the
power supply corresponds to the voltage
on the rating plate.
Do not use the machine if the mains cable or
the mains plug is damaged.
Only use extension cables that are suitable for
the power rating of the machine with a minimum
thickness of 1.5 mm
2
. If you use a extension
cable reel, always fully unroll the cable.
TECHNICAL DATA
Mains voltage V~ 230-240
Mains frequency Hz 50
Power input W 750
No-load speed min
-1
600 - 2,800
Max. sawing depth (wood) mm 110
Max. sawing stroke mm 20
Mitre angle ° +45 - -45
Number of pendulum positions 3+1
Weight kg 3.25
NOISE AND VIBRATION
Sound pressure (L
pa
) dB(A) 89
Acoustic power (L
wa
) dB(A) 100
Uncertainty (K) dB(A) 3
Vibration (wood) m/s
2
8.87
Vibration (metal) m/s
2
5.51
Uncertainty (K) m/s
2
1.5
2
Wear hearing protection.
Vibration level
The vibration emission level stated in this
instruction manual has been measured in
accordance with a standardised test given in EN
62841; it may be used to compare one tool with
another and as a preliminary assessment of
exposure to vibration when using the tool for the
applications mentioned
- using the tool for different applications, or with
different or poorly maintainted accessories,
may signicantly increase the exposure level
- the times when the tool is switched off or when
it is running but not actually doing the job, may
signi cantly reduce the exposure level
Protect yourself against the effects of vibration by
maintaining the tool and its accessories, keeping
your hands warm, and organizing your work
patterns
DESCRIPTION (FIG. A)
Your pendulum action jigsaw has been designed
for sawing wood, metal, plastics, ceramics,
rubber, etc. to any required size and in any
required shape.
1. On/off switch
2. Lock-on button
3. Speed adjustment wheel
4. Pendulum action switch
5. Guard
6. Saw blade holder
7. Saw shoe
8. Locking bolt for parallel guide
9. Dust extraction connection
10. Grip
11. Allen key
ASSEMBLY
3
Before assembly, always switch off the
machine and remove the mains plug
from the mains.
Mounting and removing the saw blade (g. B)
Refer to the table below to select the required
saw blade.
Saw blade Material
Coarse Wood
Medium Wood
Fine Steel, aluminium, plastic
Very ne Wood (curves)
2
Do not attempt to remove the guard from
the machine.
Fitting a saw blade
Fig. B
The machine is equipped with a quick t system.
Turn the clamping ring (13) of the saw blade
holder as far to the left as possible and hold it
there.
