Einhell PXC GE-CS 18 Li-Solo (4499940) [22/126] Operation

- 22 -

2. Check that your mains voltage is the same as

that marked on the rating plate of the battery

charger. Insert the power plug of the charger

(12) into the socket outlet. The green LED will

then begin to ﬂ ash.

3. Push the battery pack onto the battery char-

ger.

In section 10 (Charger indicator) you will ﬁ nd a

table with an explanation of the LED indicator on

the charger.

If the battery pack fails to charge, check for the

following:

•

voltage at the power socket

•

whether there is good contact at the charging

contacts of the charging unit

If the battery pack still fails to charge, send

•

the charger and charging adapter

•

and the battery pack

to our customer service center.

To ensure that the Li battery pack provides

long service you should take care to recharge

it promptly. You must recharge the battery pack

when you notice that the performance of the

equipment drops.

6. Operation

6.1 Insert the chain that is to be sharpened

into the chain bar (Fig. 7)

To do this, loosen the chain locking screw (1)

6.2 Set the grinding angle according to the

speciﬁ cations for your chain (Fig. 8) (nor-

mally between 30-35°)

•

Slacken the locking screw for setting the grin-

ding angle (1)

•

Set the desired grinding angle using the scale

(2)

•

Tighten the locking screw (1) again

6.3 Set the chain stopper (Fig. 9/10)

•

Fold the chain stopper (1) onto the chain

•

Pull the chain backwards against the chain

stopper (1) until the latter stops a cutting link

(A). Important! You must make sure that the

angle of the stopped cutting link coincides

with the grinding angle. If it does not, pull the

chain one link further.

•

Fold the grinding head (4) down until the grin-

ding wheel (5) is touching the chain link (A)

that is to be ground. (To do so, you can move

the chain back and forth a little using the set-

ting screw of the chain stopper (2)

6.4 Set the depth limit (Fig. 10)

Fold the grinding head (4) down and set the grin-

ding depth using the setting screw (7)

Important! The grinding depth should be set

so that the full cutting edge of the cutting link is

sharpened.

6.5 Lock the chain (Fig. 7)

Tighten the chain locking screw (1)

6.6 Grinding the chain links (Fig. 10/11)

Important!

•

Only use the equipment for sharpening saw

chains. Never grind or cut other materials.

•

Before sharpening the saw chain clamp it into

the chain bar. This will prevent jamming of the

grinding wheel caused by a loose saw chain.

•

Slowly guide the grinding wheel to the saw

blade. If the grinding wheel approaches the

saw chain too quickly or jerkily, this may

cause damage to the grinding wheel. Injuries

may result from catapulting parts!

•

Switch the appliance on at the ON/OFF

switch (1)

•

Carefully bring the grinding wheel (5) with

grinding head (4) so that it is against the set

link

•

Switch the appliance off at the ON/OFF

switch (1). Every second link in the chain

must be sharpened in this way. To know when

every second link in the entire chain has been

sharpened, mark the first link (e.g. with chalk).

Once all cutting links on one side have been

sharpened, the grinding angle must be set

to the same number of degrees on the other

side. You can then begin to sharpen the links

of the other side(without having to make any

further adjustments).

6.7 Set the depth limiter spacing (Fig. 12/13)

Once the chain has been fully sharpened, you

must make sure that the depth limiter spacing is

kept (the depth limiters (1) must be lower than the

cutting links (2). You may need to ﬁ le the depth

limiters (1) to the speciﬁ cations for your chain

using a ﬁ le (3) (not included in delivery).
