9
English
SPECIFICATIONS
Model G13BYEQ
Voltage (by areas)*
1
(230 V)
Power Input*
1
1320 W
Rated speed 10000 min
-1
Wheel
Outer dia. 125 mm
Hole Dia. 22.23 mm
Thickness 6 mm
Peripheral speed 80 m/s
Weight*
2
2.1 kg
*1 Be sure to check the nameplate on product as it is subject
to change by areas.
*2 Weight: According to EPTA-Procedure 01/2003
Electronic control
○ Soft start
Reduces recoil against the operator by managing the
number of rotations during startup.
○ 0 Voltage Re-start Protection
The 0 voltage restart protection feature prevents the
power tool from restarting after the power has been
temporarily cut off during operation.
○ Constant speed
○ Overload protection
This protection feature cuts off the power to the motor
in the event of overloading of motor or a conspicuous
reduction in rotational speed during operation.
When the overload protection feature has been
activated, the motor may stop.
In this case, release the tool switch and eliminate causes
of overloading.
After that you can use it again.
○ Overheat protection
This protection feature cuts off the power to the motor
and stops the power tool in the event of overheating of
motor during operation.
When the overheat protection feature has been
activated, the motor may stop.
In this case, release the tool switch and cool it down in a
few minutes.
After that you can use it again.
○ Brake function
Brake activates when the trigger is off .
○ Brake sytstem workable even in a power outage
The brake system works reliably even if there is a power
outage or unplugging during operation in order to avoid
unexpected accident.
NOTE
○ To prevent the tip tool from falling off , the brake will not
be applied when the switch is released right after startup
(within one second).
○ Due to HiKOKI’s continuing program of research and
development, the specifi cations herein are subject to
change without prior notice.
MOUNTING AND OPERATION
Action Figure Page
Fitting and adjusting the wheel guard 2 2
Fixing the side handle 3 2
Assembling depressed center wheel
and diamond wheel
*1 *2
43
Assembling cutting wheel
*1 *2
53
Switch operation
*3
63
Grinding angle and grinding method 7 3
Filter cleaning and replacement 8 3
Mounting and dismounting the fi lter
set
94
Selecting accessories — 25
*1 Sold separately
*2 WARNING
Before use, be sure to tighten the wheel nut with the
included wrench.
Failure to tighten could result in the wheel nut
loosening when the brake is activated during a stop.
NOTE
The wheel washer is specifi cally for this product. Do
not use it for any other product.
*3 When the 0 voltage re-start protection feature has been
activated, return the power switch to the OFF position
and wait for 1 second or more before restarting the
power tool.
MAINTENANCE AND INSPECTION
1. Inspecting the depressed center wheel
Ensure that the depressed center wheel is free of cracks
and surface defects.
2. Inspecting the mounting screws
Regularly inspect all mounting screws and ensure that
they are properly tightened. Should any of the screws be
loose, retighten them immediately. Failure to do so could
result in serious hazard.
3. Replacing supply cord
If the replacement of the supply cord is necessary, it
has to be done by HiKOKI Authorized Service Center to
avoid a safety hazard.
4. Filter cleaning and replacement
WARNING
Wear protective glasses and a dust mask when cleaning
the fi lter with an air blow gun.
Failure to do so may result in inhalation or exposure of
the eyes to debris or dust.
Remove any debris or dust adhering to the fi lter after
use. Check the fi lter periodically to ensure that it is free of
scratching, chipping, or tearing. Replace with a new fi lter if
the fi lter is damaged in any way.
NOTE
Use an air blow gun to completely remove debris and
dust from the mesh parts of the fi lter. (Fig. 8)
5. Maintenance of the motor
WARNING
Always wear protective goggles and dust respirators
when blowing air from the tail cover air hole with the use
of an air gun, etc.
Failure to observe this may result in ejected dust being
inhaled or entering your eyes.
The motor unit winding is the very “heart” of the power tool.
Exercise due care to ensure the winding does not become
damaged and/or wet with oil or water.
0000BookG13BYEQUkrRus.indb90000BookG13BYEQUkrRus.indb9 2020/06/0817:25:222020/06/0817:25:22
