STRUCTURE
CASING SKIN
» Rigid, durable structure of the casing.
» Low absorption of heat radiation and UV.
» High resistance to weather conditions.
FAN SECTION CAGE
» Improved longitudinal rigidity of the structure.
» Facilitated sections joining.
FOUNDATION
» Transport facilitation.
» High resistance of the frame to deflection.
STRUCTURAL POSTS
» Broken thermal bridges as standard.
» High resistance to weather conditions
and UV radiation.
ALUMINUM
POSTS
OF SPECIAL
CONSTRUCTION
IN EACH AHU
TYPE
STEEL SKIN COATED
WITH ALUZINC AZ 150
VVS 021-180 VVS 230-650
CORROSION RESISTANCE
Salt spray test in accordance
to ASTM B-117 standard
Number of hours
Zinc coating
20 Mu Z275
Aluzinc coating
20 Mu AZ150
Resistance of new
coating applied
to OneAir
STEEL BASE FRAME
AS STANDARD FOR ANY TYPE
OF UNITS
PROFIL V PROFIL C
Technical Specification Technical Specification
2322
