VTS Ventus VVS300 [9/55] Repair maintenance
![VTS Ventus VVS040 [9/55] Repair maintenance](/views2/1894673/page9/bg9.png)
VTS BIM -air handling units perfectly
fitted for designer’s needs.
Support for designers Support for designers
1716
VTS supports generating of air handling
units models in LOD 400
(Level Of Development) standard.
LOD
400
as standard
The VENTUS BIM families include
maintenance and service zones
of the units as standard.
These zones reserve minimum space
to secure proper maintenance and repair
conditions of the unit, and allow to avoid
any collisions with remaining building
elements or installations.
Service clearance
repair & maintenance
as standard.
