VTS Ventus VVS300 [49/55] Codes symbols
![VTS Ventus VVS400 [49/55] Codes symbols](/views2/1894673/page49/bg31.png)
CODE SYMBOL NAME
F Air lter
V Fan
C Cooler
H Heater
M Mixing box
P Plate cross-ow recuperator
R Rotary heat wheel
G Run-around coil
D Droplet eliminator
W Humidier
E Additional empty space
S Sound attenuator
CODES & SYMBOLS
Auxiliary codes
(cw)
(dx)
(xR)
(hw)
(el)
(sx)
water cooler
direct expansion cooler
coil number of rows
water heater
electric heater
sound attenuator version
CODING
VENTUS VVS - 075 R FPHV FVPD- - c d/-
VVS075-R-FPHV/VVS075-L-FVPD_CD
Range of product
Unit size as a reection of nominal airow expressed
in m
3
/h / 100. For example: 075 --> 7500 m
3
/h
Inspection side
Functions in supply tier in sequence
accordant to air treatment process
Functions in exhaust tier in sequence accordant
to air treatment process
Supply/exhaust airow mutual relation
c - counter
p - paralel
x - non applicable (individual supply or exhaust air tier)
Position of supply air outlet for supply and supply/
exhaust systems. Position of air outlet for individual
exhaust systems
u - up
d - down
Components Components
9796
