Entire range of conguration
in ClimaCAD OnLine 4 selection tool.
www.ccol4.com
Length of selected congurations
FPDV/FVPD_cd
L2
[mm]
4 392 4 392 4 392 5 490 5 490 5 490 5 856
L1
4 026 4 026 4 026 5 124 5 124 5 124 5 490
K
366 366 366 366 366 366 366
Lt
4 392 4 392 4 392 5 490 5 490 5 490 5 856
FPDMV/FVMPD_cd
L2
4 392 4 392 4 392 5 490 5 490 5 490 5 856
L1
4 026 4 026 4 026 5 124 5 124 5 124 5 490
K
366 366 366 366 366 366 366
Lt
4 392 4 392 4 392 5 490 5 490 5 490 5 856
FPDHV/FVPD_cd
L2
4 392 4 392 4 392 5 490 5 490 5 490 5 856
L1
4 392 4 392 4 392 5 490 5 490 5 490 5 856
K
0 0 0 0 0 0 0
Lt
4 392 4 392 4 392 5 490 5 490 5 490 5 856
FPDMHV/FVMPD_cd
L2
4 392 4 392 4 392 5 490 5 490 5 490 5 856
L1
4 392 4 392 4 392 5 490 5 490 5 490 5 856
K
0 0 0 0 0 0 0
Lt
4 392 4 392 4 392 5 490 5 490 5 490 5 856
FPDHCV/FVPD_cd
L2
4 392 4 392 4 392 5 490 5 490 5 490 5 856
L1
4 758 4 758 4 758 5 856 5 856 5 856 6 222
K
0 0 0 0 0 0 0
Lt
4 758 4 758 4 758 5 856 5 856 5 856 6 222
FPDMHCV/FVMPD_cd
L2
4 392 4 392 4 392 5 490 5 490 5 490 5 856
L1
4 758 4 758 4 758 5 856 5 856 5 856 6 222
K
0 0 0 0 0 0 0
Lt
4 758 4 758 4 758 5 856 5 856 5 856 6 222
VVS 150-650 - RECUPERATOR (PREMIUM PLUS)
Recommended airow range
Unit size VVS150 VVS180 VVS230 VVS300 VVS400 VVS500 VVS650
[m
3
/h]
Min airow
7 167 7 167 7 167 8 640 8 640 8 640 10 398 10 398 10 398 13 491 13 491 13 491 18 704 18 704 18 704 21 817 21 817 21 817 28 725 28 725 28 725
Max airow
19 500 15 600 15 450 23 400 18 720 18 540 29 900 23 920 23 690 39 000 31 200 30 900 52 000 41 600 41 200 71 500 57 200 56 650 84 500 67 600 66 950
H
fd
[mm]
90 120 120 120 120 120 120
H
fu
0 80 80 80 80 80 80
H 1 163 1 397 1 397 1 696 1 929 1 929 2 406
W 2 085 2 085 2 493 2 585 3 085 3 585 3 697
H
i
993 1 197 1 197 1 496 1 729 1 729 2 206
W
i
2 005 2 005 2 413 2 505 3 005 3 505 3 617
H
2
2 236 2 754 2 754 3 352 3 818 3 818 4 772
I 40 40 40 40 40 40 40
90 000
60 000
30 000
0
Nominal parameters
Full-face horizontal outlet
END (FF)
Size
WA HA WA1 HA1
VVS150 1 945 933 70 70
VVS180 1 945 1 137 70 70
VVS230 2 353 1 137 70 70
VVS300 2 445 1 436 70 70
VVS400 2 945 1 669 70 70
VVS500 3 445 1 669 70 70
VVS650 3 557 2 146 70 70
Side inlet-outlet
END (BS)
Size
HC LC HC1 LC1
VVS150 713 740 178 165
VVS180 913 740 180 165
VVS230 913 740 180 165
VVS300 1 213 740 179 165
VVS400 1 513 740 146 165
VVS500 1 513 740 146 165
VVS650 1 913 740 184 165
Side outlet
END (BS)
Size HC LC HC1 LC1
VVS150 713 740 139 202
VVS180 913 740 241 202
VVS230 913 740 142 127
VVS300 1 213 740 321 127
VVS400 1 513 740 438 127
VVS500 1 513 740 438 127
VVS650 1 913 740 676 127
DimensionSelected congurations
DIMENSIONS - VVS 150-650
- RECUPERATOR (PREMIUM PLUS)
Vertical outlet
END (US)
Size WB LB WB1 LB1
VVS150 1520 795 280 127
VVS180 1520 713 293 127
VVS230 1945 813 284 127
VVS300 1945 813 330 127
VVS400 2650 813 228 127
VVS500 3150 813 228 212
VVS650 3250 813 234 212
Vertical inlet-outlet
END (US)
Size
WB LB WB1 LB1
VVS150 1520 795 280 200
VVS180 1520 713 280 239
VVS230 1945 813 272 151
VVS300 1945 813 318 151
VVS400 2650 813 215 151
VVS500 3150 813 215 151
VVS650 3250 813 220 151
Small horizontal inlet-outlet
END (FS)
Size WA HA WA1 HA1
VVS150 1520 795 280 137
VVS180 1520 713 280 239
VVS230 1945 813 272 200
VVS300 1945 813 318 319
VVS400 2650 813 215 436
VVS500 3150 813 215 436
VVS650 3250 813 220 674
Hfd
Technical Specification Technical Specification
