ROOFTOP APPLICATIONS
SECTIONAL ROOF
» prevents water penetration
during service
» additional weather protection
VARIABLE INTAKE CONFIGURATIONS
» top, bottom and side intake options
» end – optional full face intake damper
available units
» dampers:
- gear system for even distribution of the torque
- extruded aluminum construction
- low leakage
- double wall blade construction
CURB READY RAILS
» design -overhangs the side of the curb to avoid
the need of flashing
» integrated lifting lugs
VARIABLE DISCHARGE
CONFIGURATION
» end, top, bottom and side discharge options
» optional discharge dampers and full end
discharge dampers available
