VTS American VENTUS AVS 130 [7/45] Climacad online 4 ccol 4
![VTS American VENTUS AVS 012 [7/45] Climacad online 4 ccol 4](/views2/1894743/page7/bg7.png)
Integrated with CRM,
ERP, WMA system
ClimaCAD Online 4.0 (CCOL 4)
» all browsers
DATA EXPORT TO
» all operating system
» all devices
CCOL 4.0 uses the latest technology and development platforms, which will be accessable from
anywhere in the world through our software as service models. All you need is a device with a web
browser and access to the internet.
THE VERSATILITY OF DESIGNING
» unlimited number of device congurations
» detection of illogical congurations
MANAGING YOUR OWN DATABASE
» the possibility of creating your own project
database (selection)
» the possibility of exporting own selections to
quotation by VTS technical engineers
DYNAMIC COUNTING
OF DEVICES DIMENSIONS
» CCOL offers the optimal length of the control panel
and the optimal section length adapted to the
device functions and device design
www.ccol4.com
L_1
Hd
Hf
H2
CCOL 4 IS ADJUST TO
Customized
conguration
Fast&Easy
selection
User friendly
interface
SUBMITTAL QUOTATION TECH CARD
Designer support Designer support
