WING PRO – Industrial air curtain
15
7. DANE TECHNICZNE / PARAMETERS / ТЕХНИЧЕСКИЕ ПАРАМЕТРЫ
7.1. PODSTAWOWE PARAMETRY / MAIN PARAMETERS / ОСНОВНЫЕ ПОКАЗАТЕЛИ
Parametry / Parameters /
параметры
WING PRO W150-200
WING PRO C150-200
Jednostka / units /
единицы
измерения
W150 R1
W200 R1
W150 R2
W200 R2
C150
C200
Maksymalna szerokość drzwi
/ Max. Width of the door /
максимальная ширина
двери
m
1,5
2
1,5
2
1,5
2
Maksymalna wysokość drzwi
/ Max. Height of door /
максимальная высота
двери
m
7,5
7,5
7
7
8
8
Zakres mocy grzewczej /
Heating output range /
диапазон тепловой
мощности
kW
9-32
15-48
17-58
28-88
---
Maksymalny wydatek
powietrza / Max. flow rate /
максимальный раход
воздуха
m³/h
7900
11900
7300
10700
8500
12800
Maksymalna temperatura
czynnika grzewczego / Max.
Temperature of heating
medium / максимальная
температура
теплоносителя
°C
130
---
Maksymalne ciśnienie
robocze / Max. Working
pressure / максимальное
рабочее давление
MPa
1,6
---
---
Średnica króćców
podłaczeniowych / diameter
of stub pipe connectors /
диаметр
присоединительных
патрубков
‘’
3/4
---
---
Napięcie zasilania / Supply
voltage / электропитание
V/ph/Hz
~230/1/50
Moc silnika EC / EC engine
power / электрическая
мощность (двигателя ЕС)
kW
2 x 0,25
3 x 0,25
2 x 0,25
3 x 0,25
2 x 0,25
3 x 0,25
Prąd znamionowy silnika EC
/ EC engine rated power /
номинальный ток
(двигатель EС)
A
2 x 1,3
3 x 1,3
2 x 1,3
3 x 1,3
2 x 1,3
3 x 1,3
Masa urządzenia (bez wody)
/ Weight (without water) /
масса (без воды)
kg
50,5
66,1
53,6
69,6
43,4
58,3
IP
-
54
* PL: Moc grzewcza dla parametrów czynnika grzewczego 80/60°C oraz temperatury powietrza nawiewanego 15°C
EN: Heating capacity for 80/60°C heating medium and 15°C supply air temperature
RU: Теплопроизводительность при температуре теплоносителя 80/60°C и температуре приточного воздуха 15°C.
