AERASGARD
®
RFTM - LQ - PS - CO2 - Modbus
Rev. 2022 - V31
Multifunctional indoor climate sensor
AERASGARD
®
RFTM - LQ
- PS
- CO2 - Modbus
(maximum expansion level)
with Modbus connection, in an elegant
plastic housing with snap-on lid, base with 4-hole attachment, optionally with ⁄ without display,
type variant
RFTM - CO2 - Modbus
optionally with ⁄
without setpoint potentiometer. The room sensor is used to detect the measurands air humidity (0...100 % r.H.),
temperature (0...+50°C), air quality
(0…100 % VOC), fine dust (PM) (0...1000 µg/m)
and CO2
content (0...5000 ppm) as well as a room control unit (% setpoint). Use just one device to
monitor and control the entire indoor climate effectively. This enables energy-saving room ventilation on an as-needed basis, thereby reducing operat
-
ing costs and improving well-being. It is used in offices, hotels, convention centres, apartments, shops, etc.
A long-term stable,
digital humidity and temperature sensor
guarantees exact measurement results. The air quality is determined based on a (VOC)
mixed gas sensor
. The CO2 content of the air is measured using an optical
NDIR sensor
(non-dispersive infra-red technology). An optical
fine dust
sensor
precisely detects
particulate (PM)
of the size category 0.3 to 10 micrometres. The sensor is factory-calibrated; an environmental precision
adjustment by an expert is possible. One sensor for every 30 m²of room area is recommended.
Modbus sensor
with galvanically separated RS485 Modbus interface, selectable bus termination resistance, DIP switches for setting the bus param-
eters and bus address in the currentless state, LEDs for telegram status display and two-line display (illuminated; with customised programming in
the 7-segment and dot-matrix range).
TECHNICAL DATA
Power supply: 24 V AC ⁄ DC (± 10 %)
Power consumption: t
ypically < 4.4 W ⁄ 24 V DC; < 6.4 VA ⁄ 24 V AC; peak current 200 mA
Data points: temperature [°C], relative humidity [% r.H.], air quality (VOC) [%,ppb],
fine dust (PM) [µg/m
3
], carbon dioxide (CO2) [ppm], setpoint potentiometer [%]
HUMIDITY & TEMPERATURE
Sensor (RH / °C):
digital humidity sensor with integrated temperature sensor,
low hysteresis, high long-term stability
Deviation (RH): typically
± 2.0 %
(20...80 % r. H.) at +25 °C, otherwise ± 3.0 %
Deviation (°C): typically ± 0.2 K at +25 °C
AIR QUALITY
(
VOC
)
Sensor (VOC):
VOC sensor
(metal oxide)
with automatic calibration
(VOC = volatile organic compounds)
Measuring range (VOC): 0...100 % air quality; with reference to calibration gas;
multi-range switching VOC sensitivity low, medium, high
Measuring accuracy (VOC): typically ± 20 % final value (with reference to the calibration gas)
Service life (VOC): > 60 months (under normal load conditions)
FINE DUST
(
PM
)
Sensor (PM): optical
particulate sensor
(
PM
= particulate matter),
fine-dust sensor
with laser- and soiling-resistant technology
Measuring range (PM): 0...1000 µg/m
3
Particle size (PM):
PM
2.5
(0.3...2.5 µm);
PM
10
(0.3...10 µm)
Measuring accuracy (PM): typically ± 10 µg/m
3
(± 10 % of measured value) at PM 2.5
typically ± 25 µg/m
3
(± 25 % of measured value) at PM 10
Long-term stability (PM): ± 1.2 5 µg/m
3
(± 1.25 % of measured value/year)
Service life (PM): > 10 years
CARBON DIOXIDE
(
CO2
)
Sensor (CO2): optical
NDIR sensor
(non-dispersive infra-red technology)
with automatic and manual calibration
Measuring range (CO2): 0…5000 ppm
Measuring accuracy (CO2): typically ± 30 ppm (± 3 % of measured value)
Temperature ± 5 ppm ⁄ °C or ± 0.5 % of measured value ⁄ °C
dependence (CO2): (whichever is greater)
Pressure dependence (CO2): ± 0.13 % ⁄ mm Hg
Long-term stability (CO2): < 2 % in 15 years
Gas exchange (CO2): Diffusion
Ambient temperature: 0...+ 50 °C
Permitted humidity: 0…95 % r. H. (non-precipitating air)
Warm up time: approx. 1 hour
Response time: < 2 minutes
Electrical connection: 0.2 - 1.5 mm
2
, via push-in terminal
Housing: plastic, material ABS, colour pure white (similar to RAL 9010)
Dimensions: 98 x 98 x 33 mm (Baldur 2)
Mounting:
wall mounting or on in-wall flush box, Ø 55 mm, base with 4 holes,
for attachment
to vertically or horizontally installed in-wall flush boxes for rear cable entry,
with predetermined breaking point for top/bottom cable entry for surface-mounted installation
Protection class: III (according to EN 60 730)
Protection type:
IP 30
(according to EN 60 529)
Standards: CE conformity, electromagnetic compatibility according to EN 61 326,
EMC Directive 2014 ⁄ 30 ⁄ EU, Low Voltage Directive 2014 ⁄ 35 ⁄ EU
Optional:
Display with illumination,
2-line, cutout approx. 36 x 15 mm (W x H),
to display actual humidity, actual temperature, air quality, of the fine-dust and CO2 content (cyclic)
or a selectable parameter (static) or an individually programmable display value
