Startup
Startup Startup
Startup
Topreventseriousinjury,onlyoperateReactor
withallcoversandshroudsinplace.
NOTICE NOTICE
NOTICE
Propersystemsetup,startup,andshutdown
proceduresarecriticaltoelectricalequipment
reliability.Thefollowingproceduresensuresteady
voltage.Failuretofollowtheseprocedureswill
causevoltageuctuationsthatcandamage
electricalequipmentandvoidthewarranty.
1.Checkuidinletlterscreens.
Beforedailystartup,ensurethatthe
uidinletscreensareclean.See
FlushInletStrainerScreen,page63
2.CheckISOlubricationreservoir.
ChecklevelandconditionofISOlubedaily.See
PumpLubricationSystem,page64.
3.UseAandBDrumLevelSticks(24M174)to
measurethemateriallevelineachdrum..If
desired,thelevelcanbeenteredandtrackedin
theADM.SeeAdvancedSetupScreens,page34.
4.Checkgeneratorfuellevel.
NOTICE NOTICE
NOTICE
Runningoutoffuelwillcausevoltage
uctuationsthatcandamageelectrical
equipmentandvoidthewarranty.Donotrun
outoffuel.
5.ConrmmainpowerswitchisOFFbeforestarting
generator.
6.Ensurethemainbreakeronthegeneratorisin
theoffposition.
7.Startthegenerator.Allowittoreachfulloperating
temperature.
8.TurnmainpowerswitchON.
TheADMwilldisplaythefollowingscreenuntil
communicationandinitializationiscomplete.
333023T 43
