JogMode
Circulation Circulation
Circulation
Through Through
Through
Gun Gun
Gun
Manifold Manifold
Manifold
NOTICE NOTICE
NOTICE
Topreventequipmentdamage,donotcirculate
uidcontainingablowingagentwithoutconsulting
withyourmaterialsupplierregardinguid
temperaturelimits.
NOTE: NOTE:
NOTE:
Optimumheattransferisachievedatlower
uidowrateswithtemperaturesetpointsatdesired
drumtemperature.Lowtemperaturerisedeviation
errorsmayresult.
Circulatinguidthroughthegunmanifoldallows
rapidpreheatingofthehose.
1.Installgunuidmanifold(P)onaccessory
circulationkit(CK).Connecthighpressure
circulationlines(R)tocirculationmanifold.
The Fusion AP gun manifold is shown.
CK CK
CK
Gun Gun
Gun
Manual Manual
Manual
246362FusionAP309818
256566
FusionCS
313058
2.Routecirculationlinesbacktorespective
componentAorBsupplydrum.Use
hosesratedatthemaximumworking
pressureofthisequipment.See
TechnicalSpecications,page74.
3.FollowproceduresfromStartup,page43.
4.Turnmainpowerswitchon
.
5.Settemperaturetargets.SeeTargets,page39.
6.Press
tocirculateuidinjogmodeuntil
AandBtemperaturesreachtargets.See
JogMode,page47formoreinformationabout
jogmode.
Jog Jog
Jog
Mode Mode
Mode
Jogmodehastwopurposes:
•Itcanspeeduidheatingduringcirculation.
•Itcaneasesystemushingandpriming.
1.Turnmainpowerswitchon
.
2.Presscirculate
toenterjogmode.
3.Pressupordown
tochangejogspeed
(J1throughJ20).
NOTE: NOTE:
NOTE:
Jogspeedscorrelateto3-30%ofmotor
power,butwillnotoperateover700psi(4.9
MPa,49bar)foreitherAorB.
4.Press
tostartmotor.
5.Tostopthemotorandexitjogmodepress
or.
333023T
47
