Graco Reactor 2 E-30 FP2110 [60/78] Pressure relief procedure
![Graco Reactor 2 E-30 FP2110 [60/78] Pressure relief procedure](/views2/1900325/page60/bg3c.png)
Spraying
Pressure Pressure
Pressure
Relief Relief
Relief
Procedure Procedure
Procedure
FollowthePressureReliefProcedure
wheneveryouseethissymbol.
Thisequipmentstayspressurizeduntilpressure
ismanuallyrelieved.Tohelppreventserious
injuryfrompressurizeduid,suchasskininjection,
splashinguidandmovingparts,followthe
PressureReliefProcedurewhenyoustopspraying
andbeforecleaning,checking,orservicing
equipment.
The Fusion AP gun is shown.
1.Presstostopthepumps.
2.Turnoffallheatzones.
3.Relievepressureingunandperformgun
shutdownprocedure.Seeyourgunmanual.
4.ClosegunuidinletvalvesAandB.
5.Shutofffeedpumpsandagitator,ifused.
6.Routeuidtowastecontainersorsupplytanks.
TurnPRESSURERELIEF/SPRAYvalves(SA,
SB)toPRESSURERELIEF/CIRCULATION
.
Ensuregaugesdropto0.
7.Engagegunpistonsafetylock.
8.Disconnectthegunairlineandremovethegun
uidmanifold.
60 333023T
