Spraying
Spraying Spraying
Spraying
The Fusion AP gun is shown.
1.Engagegunpistonsafetylockandclosegun
uidinletvalvesAandB.
Fusion Fusion
Fusion
Probler Probler
Probler
2.Attachgunuidmanifold.Connectgunairline.
Openairlinevalve.
3.Adjustthegunairregulatortodesiredgunair
pressure.Donotexceedthemaximumrated
airpressure.
4.SetPRESSURERELIEF/SPRAYvalves(SA,
SB)toSPRAY
.
5.Verifyheatzonesareonandtemperatures
andpressuresareontarget,see
Homescreen,page38.
6.Openuidinletvalvelocatedateachpumpinlet.
7.Presstostartmotorandpumps.
8.Checkuidpressuregauges(GA,GB)to
ensureproperpressurebalance.Ifimbalanced,
reducepressureofhighercomponentby
slightly slightly
slightly
turningPRESSURERELIEF/SPRAY
valveforthatcomponenttowardPRESSURE
RELIEF/CIRCULATION
untilgaugesshow
balancedpressures.
48 333023T
