Startup
11.PresstoactivateADM.
12.Ifnecessary,setuptheADMinSetupMode.See
AdvancedDisplayModule(ADM)Operation,
page31.
13.Preheatthesystem:
a.Press
toturnonhoseheatzone.
NOTE: NOTE:
NOTE:
Inordertorunwithoutauid
temperaturesensorinHoseResistance
Mode,acalibrationfactormustbesaved.
SeeCalibrationProcedure,page54.
Thisequipmentisusedwithheateduid
whichcancauseequipmentsurfacesto
becomeveryhot.Toavoidsevereburns:
•Donottouchhotuidorequipment.
•Donotturnonhoseheatwithoutuid
inhoses.
•Allowequipmenttocoolcompletely
beforetouchingit.
•Wearglovesifuidtemperatureexceeds
110°F(43°C).
Thermalexpansioncancause
overpressurization,resultinginequipment
ruptureandseriousinjury,includinguid
injection.Donotpressurizesystemwhen
preheatinghose.
b.Ifyouneedtocirculateuidthroughthe
systemtopreheatthedrumsupply,see
CirculationThroughReactor,page46.
Ifyouneedtocirculatematerialthrough
theheathosetothegunmanifold,see
CirculationThroughGunManifold,page47.
c.Waitforthehosetoreachsetpoint
temperature.
NOTE: NOTE:
NOTE:
Hoseheat-uptimemayincreaseat
voltageslessthan230VACwhenmaximum
hoselengthisused.
d.Press
toturnonAandBheatzones.
333023T 45
