75
14. Application Functions
Read Chapter 7 Before Use of These Pages
(Operational condition setting check display)
(Operation)
The Animal symbol is illuminated when this mode is active. Also a triangular symbol to indicate the cur-
rently set operational condition is illuminated in the right end of the display (See the above).
1 Load the weighing vessel and press the [O/T]
key to zero the display.
2 Load the sample (animal) with a mass more
than 50 times the Zero Range.
3 When the measurement reaches stability crite-
ria of Animal Weighing, the weighed value is auto-
matically output.
4 Unload the animal or press the [O/T] key.
5 When the mass display becomes less than 10
times the Zero Range and stability is detected,
automatic zeroing occurs.
The mass of any residue remaining on the bal-
ance (excrement or fur) is canceled and returns to
zero display.
Start weighing from the above step 2 for the next
animal.
When Cond 3 is selected
When Cond 2 is selected
When Cond 1 is selected
W
W
W
(Display)
