30
B/G/H
CABLE TV (1)
CABLE TV (2)
ITALY
D/K
CABLE TV (1)
CABLE TV (2)
CABLE TV
L
I
Troubleshooting
Here are some simple solutions to some problems which may affect the picture and sound.
Problem
No picture (screen is dark), no sound
Poor or no picture (screen is dark), but sound is OK
Poor picture quality when watching an RGB video source
Good picture but no sound
No colour for colour programmes
Remote Commander does not function
If you continue to have problems, have your TV serviced by qualified personnel. Never open the casing yourself.
Specifications
This product complies with the EU Directive 89/336/EEC.
Solution
• Plug in the TV in.
• Press u on the TV (if u indicator is on, press ; or a programme number
on the Remote Commander).
• Check the aerial connection.
• Check if the selected video source is on.
• Press
to enter the PICTURE CONTROL menu and adjust the
brightness, contrast and colour.
• Press … repeatedly to select
.
• Press . +.
• Check loudspeakers connection.
• If o is displayed on the screen, press o.
• Press
to enter the PICTURE CONTROL menu, select Reset, then
press the joystick to confirm.
• The batteries are weak.
Sound output 2 × 30 W (music power)
2 × 15 W (RMS)
Centre SP input 50 W (RMS) (using as the centre
speaker)
Power consumption 155 W
Dimensions (W × H × D) 980 × 834 × 399 mm
(38
5
/8 × 32
7
/8 × 15
3
/4 inches)
Mass 27 kg (59 lbs 8 oz)
Supplied accessories See page 6.
Other features Digital comb filter (High resolution)
FASTEXT
DCI (Digital Constant Image)
Design and specifications are subject to change without notice.
Receivable Channels and Channel Displays
Indication on the
screen
C02 C03 C04..C12
C21..C69
S01 S02..S41
S42..S46 S01..S10
S11..S20
C11..C69
C02..C12 C21..C69
S01 S02..S41
S42 S43..S46
S02, S03..S17,
S21..S41
C01..C12 C21..C69
C21..C68
Receivable
channels
E2..12 21..69
S1..41
S01..S05 M1..M10
U1..U10
A B C D E F G H H1
H2 21..69
R01..R12 R21..R69
B..Q, S21..41
F2..F10 F21..F69
B21..B68
Television system B/G/H, D/K, I, L
Colour system PAL/SECAM
NTSC 3.58/4.43 (VIDEO IN)
Channel coverage See “Receivable channels and
channel displays” at the bottom.
Projected picture size 40 inches
Approx. 101.6 cm measured
diagonally
Terminals
Rear Center speaker input terminals,
2 terminals
(L, R), audio outputs - phono
jacks
1, 21-pin Euro connector
(CENELEC standard)
- inputs for audio and video signals
- inputs for RGB
- outputs of TV audio and video
signals
: 2/q 2, 21-pin Euro connector
- inputs for audio and video signals
- inputs for S video
- outputs for audio and video signals
(slectable)
: 4/q 4, 21-pin Euro connector
- inputs for audio and video signals
- inputs for S video
- outputs for audio and video signals
(monitor out)
Front q 3, S video inputs - 4-pin DIN
… 3, video inputs - phono jacks
≤ (L, R), audio inputs - phono jacks
2, headphones jack - stereo minijack
